01-0014-01 Specifications
Manufacturer: Dongguan Zhongxiang
Part Number: 01-0014-01
Connector Type: PCIe ATX power connector
Connector Function: Board mounted header
Number of Positions: 8 positions
Pitch: 4.2 mm
Orientation: Right angle
Termination Style: Through hole
Mounting Type: PCB mount
Contact Style: Power contacts
Current Rating: High current power connector
Application Standard: PCIe ATX power interface
Housing Material: High temperature thermoplastic
Operating Temperature Range: Suitable for power applications
Key Features
The 01-0014-01 supports reliable high current power delivery in PCIe ATX applications. Additionally, the 8 position layout matches common graphics card power interfaces. Moreover, the 4.2 mm pitch allows secure spacing for higher current handling. Furthermore, the right angle design supports horizontal PCB layouts and reduced vertical clearance.
Applications
PCIe graphics card power connectors
ATX power distribution boards
Desktop power supply assemblies
GPU riser and adapter boards
Industrial computing power interfaces
Embedded PC power backplanes
High current PCB power routing
System power expansion modules
Product Overview
The Dongguan Zhongxiang 01-0014-01 PCIe ATX connector header is designed for dependable power delivery in computing and industrial systems. Specifically, it features an 8 position configuration commonly used for PCIe auxiliary power connections. As a result, it supports stable power transfer to high demand components such as graphics cards. Moreover, the 4.2 mm pitch provides adequate spacing to handle elevated current levels safely. Therefore, electrical performance and thermal stability are improved.
In addition, the right angle through hole design allows the connector to sit parallel to the PCB surface. Furthermore, this orientation helps reduce overall system height in compact enclosures. Consequently, it integrates well into dense layouts where vertical clearance is limited. Because of its PCB mount construction, mechanical retention is strong during repeated insertion cycles. As a result, long term reliability is maintained in power critical systems.
Overall, this connector delivers a practical balance of current handling, mechanical strength, and layout flexibility. Therefore, it is a solid choice for PCIe ATX power applications requiring a right angle PCB mounted solution.
