0501010.WR Specifications
Manufacturer: Littelfuse
Part Number: 0501010.WR
Product Type: Surface mount fuse
Series: 501 High Current Fast-Acting Fuse
Current Rating: 10 A
Voltage Rating: 32 V DC
Fuse Type: Fast blow
Package / Case: 1206 (3216 metric)
Mounting Type: Surface mount (SMD)
Interrupt Rating: 150 A at 32 V DC
Body Material: Ceramic
Termination Style: Solder pad
Operating Temperature Range: -55 °C to +150 °C
RoHS Compliance: Yes DigiKey+1
Key Features
The 0501010.WR provides reliable overcurrent protection for surface mount designs. Additionally, the fast-acting fuse characteristic helps limit fault energy. Moreover, its ceramic body offers high thermal stability. Furthermore, the 1206 package supports automated PCB assembly. Because of this, it fits compact circuit protection roles effectively. Littelfuse
Applications
Power regulator and VRM protection
Voltage-controlled power circuits
DC-DC converter input protection
Notebook and portable electronics
Industrial power distribution boards
Embedded system safety protection
Consumer electronics power lines
Telecommunications equipment protection
Product Overview
The Littelfuse 0501010.WR surface mount fuse is part of the 501 series of high current fast-acting fuses designed for overcurrent protection. Specifically, it supports a 10 A current rating and a 32 V DC voltage rating, which makes it suitable for many low-voltage power systems. As a result, designers can use it to protect power supply and regulator outputs. Additionally, the fast blow performance helps quickly interrupt fault conditions, thus reducing potential damage to downstream components.
Moreover, the ceramic body enhances thermal durability, which improves performance in high ambient temperature environments. Furthermore, the compact 1206 package and surface mount termination support automated assembly and high-density PCB layouts. Therefore, this fuse integrates well into both consumer and industrial designs. Because of its robust interrupt rating, it also handles transient spikes and inrush conditions effectively. Overall, the 0501010.WR delivers dependable overcurrent protection for a range of electronic systems.
