10M16DAF484C8G Specifications
Manufacturer: Intel (formerly Altera)
Part Number: 10M16DAF484C8G
Product Type: FPGA – Field Programmable Gate Array
Family: MAX® 10
Logic Elements: 16,000
Embedded Memory: 504 Kbits
Number of I/Os: 200
Operating Temperature Range: 0°C to +85°C (Commercial)
Package / Case: 484-BGA
Mounting Type: Surface Mount
Voltage Supply: 1.2V Core, 3.3V I/O
Speed Grade: 8
Features: On-chip Flash, PLL, ADC
Configuration: Internal Flash
RoHS Status: RoHS Compliant
Key Features
The 10M16DAF484C8G is part of Intel’s MAX® 10 FPGA family. It integrates 16,000 logic elements and 504 Kbits of embedded memory into a compact, power-efficient design. The device also includes on-chip flash memory, a phase-locked loop (PLL), and an analog-to-digital converter (ADC). These features reduce the need for external components. Its 484-BGA package offers up to 200 I/Os, supporting flexible system design. Additionally, the internal flash enables instant-on operation, which is critical for time-sensitive applications.
Applications
Industrial control systems
Communications and networking hardware
Consumer electronics and smart devices
Test and measurement equipment
Motor control and power conversion
Embedded platforms with mixed-signal integration
Product Overview
The 10M16DAF484C8G delivers efficient logic integration for embedded and industrial systems. With 16,000 logic elements and embedded memory, it offers essential digital functionality in a single device. Its internal flash configuration simplifies board design while enabling quick startup. Furthermore, the on-chip PLL and ADC reduce the need for external components, which helps save space and cost. Operating on a 1.2V core supply and supporting 3.3V I/O, it easily fits into mixed-voltage systems. The 484-BGA package supports up to 200 I/Os, allowing for flexible interfacing with other components. As a result, this FPGA is ideal for designers seeking a reliable, compact, and feature-rich solution.
