115-1-A-5/1D Specifications
Manufacturer: Pickering Electronics
Part Number: 115-1-A-5/1D
Device Type: Reed relay
Relay Configuration: SPST normally open
Contact Form: 1 Form A
Coil Voltage: 5 V DC
Coil Type: DC coil with internal diode
Contact Type: Dry reed contact
Switching Voltage: High-voltage signal capable
Contact Resistance: Low contact resistance design
Isolation Performance: High isolation between contacts
Magnetic Shielding: Internal magnetic screen
Package Type: Single-in-line SIP
Mounting Style: Through-hole
Operating Temperature Range: -20 °C to +85 °C
Packaging Type: Tube
Category: Hardware
Key Features
This reed relay delivers precise low-level signal switching. It uses a normally open contact. As a result, control logic stays simple. The internal diode protects the drive circuit. Therefore, coil switching remains safe. The magnetic shield limits external interference. In addition, the dry contact design supports high isolation. This improves signal integrity. The SIP package supports dense layouts.
Applications
Automated test equipment switching
Signal multiplexing systems
Instrumentation measurement paths
Telecommunications test circuits
Low-power control interfaces
Data acquisition front ends
Product Overview
The 115-1-A-5/1D from Pickering Electronics is designed for accurate signal control. First, the 5 V coil energizes the relay quickly. This closes the reed contact cleanly. Next, the dry contact structure maintains low leakage. Because of this, sensitive signals remain stable.
In addition, the internal diode reduces voltage spikes. This protects driver electronics. The internal magnetic screen improves repeatability. As a result, switching performance stays consistent. The through-hole SIP package provides strong PCB retention. Therefore, mechanical reliability improves over time.
Overall, this reed relay offers precision and durability. It fits well in test and measurement systems. Engineers rely on it when clean signal switching matters.
