11828-2DA Specifications
Manufacturer: Mill Max
Part Number: 11828-2DA
Product Type: Pin header
Connector Type: Single-row male header
Number of Positions: 2 positions
Pitch: 2.54 mm
Orientation: Right-angle
Termination Style: Through-hole
Contact Material: Brass
Contact Plating: Gold over nickel
Insulation Material: High-temperature thermoplastic
Mounting Type: PCB mount
Operating Temperature Range: -55 °C to +125 °C
Key Features
The 11828-2DA provides a compact and reliable right-angle pin header interface. Additionally, its gold-plated contacts improve conductivity and resist corrosion. Moreover, the 2.54 mm pitch supports compatibility with a wide range of sockets and jumpers. Furthermore, the through-hole design enhances mechanical stability on the PCB.
Applications
Prototype boards and development kits
Board-to-board signalling
Embedded system interfaces
Right-angle jumper connections
Industrial control backplanes
Low-power signal routing
Test and measurement fixtures
General-purpose PCB connectivity
Product Overview
The Mill Max 11828-2DA right-angle pin header offers a dependable interconnect solution for PCB designs requiring horizontal mating. Specifically, its 2-position layout with a standard 2.54 mm pitch allows easy integration with jumpers, sockets, and mating headers. As a result, board layouts remain compact without sacrificing compatibility with common hardware. Moreover, the gold-over-nickel plating improves signal transmission and protects contact surfaces from oxidation. Therefore, the connector delivers long-lasting electrical performance.
In addition, the through-hole mounting style provides robust mechanical retention, which supports repeated assembly cycles and handling. Furthermore, the high-temperature thermoplastic insulation maintains dimensional integrity through solder reflow and thermal cycling. Consequently, the 11828-2DA fits well across a variety of consumer, industrial, and embedded electronic designs. Because of its straightforward design and dependable performance, this pin header remains a practical choice for basic PCB interconnection needs.
