1613-3 Specifications
Manufacturer: Keystone Electronics
Part Number: 1613-3
Product Type: PCB terminal block
Number of Positions: 2 positions
Pitch: 5.08 mm
Orientation: Straight
Mounting Type: Through-hole
Termination Style: Screw clamp
Contact Material: Brass
Contact Plating: Tin
Housing Material: Thermoplastic
Rated Voltage: 300 V
Rated Current: 15 A
Wire Gauge Range: 12 AWG to 26 AWG
Operating Temperature Range: -40 °C to +105 °C
Key Features
The 1613-3 provides secure wire termination for PCB-mounted power and signal connections. Additionally, the two-position layout supports simple and efficient circuit routing. Moreover, the through-hole design improves mechanical strength. Furthermore, the screw clamp termination ensures reliable wire retention.
Applications
Industrial control boards
Power distribution PCBs
Embedded controller assemblies
Automation equipment
HVAC control systems
Power supply modules
Test and measurement hardware
General-purpose PCB interconnects
Product Overview
The Keystone Electronics 1613-3 PCB terminal block is designed for dependable wire-to-board connections. Specifically, it features a two-position layout that supports clean and organized wiring. As a result, system assembly becomes easier and more consistent. Moreover, the 5.08 mm pitch allows adequate spacing for higher current applications. Therefore, it suits both power and control circuits.
In addition, the through-hole mounting style provides strong mechanical anchoring to the PCB. Furthermore, this design improves durability during wire installation and maintenance. Consequently, the terminal block performs well in environments with vibration or repeated servicing. The screw clamp termination also supports a wide wire gauge range. As a result, installation flexibility is increased.
The thermoplastic housing offers electrical insulation and thermal stability. Moreover, the tin-plated brass contacts ensure good conductivity and corrosion resistance. Therefore, long-term electrical performance remains reliable. The rated voltage and current further support use in industrial systems. Consequently, this component fits demanding operating conditions.
Overall, the 1613-3 terminal block delivers a balance of durability, simplicity, and electrical reliability. Therefore, it is a practical choice for designers needing dependable two-position PCB terminal connections.
