3224W-1-502E Specifications
Manufacturer: Bourns
Part Number: 3224W-1-502E
Product Type: Surface Mount Multi-Turn Cermet Trimmer Potentiometer
Resistance Value: 5 kΩ
Adjustment Type: Top Adjust
Number of Turns: 12
Power Rating: 0.25 W (1/4 W)
Voltage Rating: 300 V
Tolerance: ±10%
Temperature Coefficient: ±100 ppm/°C
Mounting Type: Surface Mount Device (SMD)
Termination Style: J Lead
Operating Temperature Range: -65°C to +150°C
Body Size: 4.8 mm × 3.5 mm × 5.3 mm
RoHS Status: RoHS Compliant
Key Features
The 3224W-1-502E is a surface mount multi-turn cermet trimmer potentiometer from Bourns, designed for precise resistance adjustments in electronic circuits. It offers a resistance value of 5 kΩ with a top adjust mechanism, facilitating easy access during calibration. The device features 12 turns, allowing for fine resolution in resistance setting. With a power rating of 0.25 W and a voltage rating of 300 V, it is suitable for various electronic applications. The potentiometer maintains a tolerance of ±10% and a temperature coefficient of ±100 ppm/°C, ensuring consistent performance across a wide temperature range from -65°C to +150°C. Its compact dimensions of 4.8 mm × 3.5 mm × 5.3 mm make it ideal for space-constrained designs. The J lead termination style supports secure surface mounting, and compliance with RoHS standards underscores its environmental responsibility.
Applications
Precision calibration in electronic circuits.
Offset and gain control in amplifiers.
Sensor signal adjustment in industrial equipment.
Frequency tuning in communication devices.
Voltage division in power supplies.
Product Overview
Bourns’ 3224W-1-502E trimmer potentiometer is engineered for applications requiring precise resistance adjustments. Its 12-turn design allows for fine-tuned calibration, making it ideal for settings where accuracy is paramount. The top adjust feature provides convenient access for manual adjustments during assembly or maintenance. With a robust power and voltage rating, it can be employed in various electronic circuits without compromising reliability. The device’s tolerance and temperature coefficient ensure stable operation across different environmental conditions. Its surface mount configuration, featuring J lead terminations, supports efficient PCB layout and assembly processes. Overall, the 3224W-1-502E combines precision, reliability, and ease of integration, making it a valuable component in numerous electronic applications.
