35363-0260

35363-0260 Specifications

Manufacturer: TE Connectivity
Part Number: 35363-0260
Product Type: Header
Series: AMPMODU Mod IV
Number of Positions: 60
Pitch: 2.54mm
Number of Rows: 2
Mounting Type: Through Hole
Orientation: Vertical
Contact Material: Phosphor Bronze
Contact Plating: Gold (0.381µm) on mating area, Tin on solder tail
Housing Material: Polyamide, UL 94V-0
Current Rating: 1A per contact
Voltage Rating: 250V
Operating Temperature Range: -55°C to +105°C
Flammability Rating: UL 94V-0
Durability: 250 mating cycles
PCB Thickness Compatibility: 1.57mm

Key Features

• High-density 60-position header with 2.54mm pitch.
• Gold-plated contacts ensure reliable, low-resistance connections.
• UL 94V-0 rated polyamide housing for durability and high temperature resistance.
• Vertical through-hole mounting ideal for compact designs.
• High mating cycle durability of up to 250 cycles.

Applications

• Consumer electronics requiring secure and durable PCB connections.
• Telecommunications equipment for reliable signal and power transmission.
• Industrial control systems needing high-density, reliable connections.
• Medical devices where secure and stable electronic connections are essential.
• Automotive applications for compact and reliable board-to-board connections.

Product Overview

The TE Connectivity 35363-0260 is a 60-position vertical header designed for high-density, reliable connections in through-hole mounted applications. With a 2.54mm pitch and gold-plated contacts, this header ensures high-quality electrical performance and longevity. Ideal for a wide range of industries, including consumer electronics, telecommunications, and automotive, it offers durability and high-temperature resistance with a UL 94V-0 rated polyamide housing.
