514FBA000215BAGR

514FBA000215BAGR

$10.00

XTAL OSC XO 27.0000MHZ LVDS SMD
  • Manufacturer: Skyworks Solutions Inc
  • Part Number: 514FBA000215BAGR
  • Packaging: Tape and Reel
  • Quantity: Each
  • Datecode: 2244

Availability: 4720 in stock

SKU TSX013 Category Brand:

514FBA000215BAGR Specifications

Manufacturer: Skyworks Solutions, Inc.
Part Number: 514FBA000215BAGR
Product Type: Programmable XO (Oscillator)
Frequency: 25.000 MHz
Supply Voltage: 1.8V
Output Type: LVCMOS
Stability: ±25 ppm
Tolerance: Factory-programmed
Operating Temperature Range: -40°C to +85°C
Package / Case: 2.0mm x 1.6mm SMD (4-pad)
Mounting Type: Surface Mount
Current Consumption: 2.0 mA (typical at 1.8V)
Startup Time: 5 ms (typical)
Phase Jitter (12kHz–20MHz): 800 fs (typical)
RoHS Status: RoHS Compliant

Key Features

The 514FBA000215BAGR is part of Skyworks’ Si514 oscillator series, known for its ultra-flexible frequency programmability and low jitter. This version outputs a 25 MHz clock signal with a supply voltage of just 1.8V, making it a strong choice for power-sensitive applications. Its compact 2.0mm x 1.6mm package supports dense layouts. Furthermore, the oscillator delivers excellent phase jitter performance, helping ensure clean signal timing in high-speed systems.

Applications

Wireless and RF systems
Precision timing circuits
Embedded controllers
Industrial automation
Networking and communication equipment
Consumer electronics

Product Overview

The 514FBA000215BAGR oscillator from Skyworks Solutions is a factory-programmed, ultra-low jitter device designed for high-performance timing. Operating at 25 MHz with a tight ±25 ppm frequency stability, it suits a wide range of timing-sensitive applications. Its ultra-low phase jitter of 800 femtoseconds enhances signal clarity, making it a strong choice for RF, networking, and communication systems. In addition, the 1.8V operating voltage and minimal current draw allow for integration into low-power designs. Housed in a miniature 2.0mm x 1.6mm surface-mount package, the device provides reliable startup and long-term frequency stability. This makes the 514FBA000215BAGR an excellent choice for engineers needing programmable, high-quality clock generation in compact spaces.
