5M240ZT100C5N

5M240ZT100C5N Specifications

Manufacturer: Intel (formerly Altera)
Part Number: 5M240ZT100C5N
Product Type: Complex Programmable Logic Device (CPLD)
Family: MAX® V
Logic Elements: 240
Macrocells: 192
User I/O Pins: 79
Embedded Memory: 8 Kb user flash memory
Supply Voltage: 1.8 V core, 3.3 V I/O
Speed Grade: 5
Maximum Frequency: 304 MHz
Package / Case: 100-TQFP (14 × 14 mm)
Mounting Type: Surface Mount
JTAG Support: Yes
Configuration: Flash-based, instant-on
Operating Temperature Range: 0°C to +85°C
RoHS Status: RoHS Compliant

Key Features

The 5M240ZT100C5N is part of the MAX V family from Intel, offering a compact and reliable solution for embedded control logic. It integrates 240 logic elements and 192 macrocells, making it suitable for a wide range of control applications. Because it features flash-based configuration, the device powers up instantly without the need for external memory. Designers can benefit from onboard flash storage, which supports simple updates and non-volatile logic retention. Additionally, this CPLD consumes very little power in standby, helping reduce overall energy demand in portable or low-power systems.

Applications

Programmable interface logic in industrial motor controllers
Power sequencing and reset logic in embedded computing platforms
Signal decoding in medical diagnostic devices
Peripheral control in automotive lighting and instrument clusters
Glue logic in telecommunications infrastructure systems

Product Overview

The 5M240ZT100C5N from Intel is a cost-effective CPLD designed to simplify logic implementation while reducing board space and power draw. It is built on a non-volatile flash architecture, allowing for fast configuration without an external boot source. With up to 79 user I/O pins and support for multiple voltage standards, it fits seamlessly into mixed-signal environments. Moreover, its compact 100-TQFP package enables designers to add custom logic in tight spaces. As a result, it is well-suited for flexible control systems where space, speed, and reliability all matter.
