5M240ZT144C5N Specifications
Manufacturer: Intel (formerly Altera)
Part Number: 5M240ZT144C5N
Product Type: CPLD – Complex Programmable Logic Device
Family: MAX V
Logic Elements / Macro Cells: 240 LE / 192 MC
User I/O Pins: 116
Embedded Memory: 8,192 bits
Supply Voltage: 1.8 V Core, 3.3 V I/O
Speed Grade: 5
Maximum Operating Frequency: 118.3 MHz
Package / Case: 144-TQFP
Mounting Type: Surface Mount
JTAG Support: Yes
I/O Standards Supported: LVTTL, LVCMOS
Operating Temperature Range: 0°C to +85°C
RoHS Status: RoHS Compliant
Key Features
The 5M240ZT144C5N is a member of Intel’s MAX V family of CPLDs, offering a cost-effective, low-power solution for logic implementation. With 240 logic elements and embedded flash memory, it delivers flexibility for system control, interface bridging, and I/O expansion. This device features an efficient architecture optimized for fast design iteration and system integration. Additionally, it supports in-system programming via JTAG and is ideal for applications requiring minimal board space. Because it comes in a 144-pin TQFP package, it simplifies layout and enhances compatibility with standard SMT processes.
Applications
Industrial motor controllers with configurable logic sequencing
Interface bridging in communication infrastructure equipment
Programmable control in commercial-grade embedded systems
Consumer electronics needing flexible logic operation
Test and measurement platforms using digital timing control
Product Overview
The 5M240ZT144C5N CPLD from Intel provides engineers with a reliable and scalable logic platform. It is designed to meet the demands of programmable control and glue logic applications while maintaining ultra-low static power consumption. With over 100 user I/O pins and multiple I/O standards supported, this device adapts to a broad range of system requirements. The embedded memory and flash-based configuration offer robust performance without external boot devices. As part of the MAX V family, it supports easy in-system programmability, making it a smart choice for modern, adaptable logic design.
