744316100

744316100 Specifications

Manufacturer: Würth Elektronik
Part Number: 744316100
Product Type: Shielded Wirewound Power Inductor
Inductance: 1 µH ±20%
DC Resistance (DCR): 4.75 mΩ maximum
Saturation Current (Isat): 11.5 A
RMS Current (Irms): 11.5 A
Self-Resonant Frequency (SRF): 158 MHz typical
Operating Temperature Range: -40°C to +150°C
Package Dimensions: 5.5 mm (L) x 5.3 mm (W) x 4.3 mm (H)
Mounting Type: Surface Mount
Shielding: Shielded
Core Material: WE-PERM 2
Compliance: RoHS Compliant, AEC-Q200 Qualified

Key Features

The 744316100 from Würth Elektronik is a shielded wirewound power inductor designed for high-efficiency energy storage in compact electronic circuits. With an inductance of 1 µH and a maximum DC resistance of 4.75 mΩ, it supports saturation and RMS currents up to 11.5 A. Its WE-PERM 2 core material ensures stable inductance and low core losses across a broad frequency range. The shielded construction minimizes electromagnetic interference (EMI), making it suitable for noise-sensitive applications. Additionally, its compact 5.5 mm x 5.3 mm x 4.3 mm package facilitates integration into space-constrained designs.

Applications

DC-DC converters in automotive electronic control units (ECUs)
Power supply modules in telecommunications equipment
Voltage regulation in industrial automation systems
Energy storage in portable consumer electronics
Noise filtering in medical diagnostic devices

Product Overview

Würth Elektronik’s 744316100 power inductor offers a balance of high performance and compact size, making it ideal for modern electronic applications requiring efficient energy storage and minimal EMI. Its shielded design and WE-PERM 2 core contribute to reliable operation in environments with stringent noise requirements. The inductor’s ability to handle significant saturation and RMS currents ensures suitability for demanding power management tasks. Furthermore, its AEC-Q200 qualification and RoHS compliance reflect Würth Elektronik’s commitment to quality and environmental responsibility.
