8302AMLF Specifications
Manufacturer: Renesas Electronics
Part Number: 8302AMLF
Product Type: 1:2 LVCMOS Fanout Buffer
Number of Outputs: 2
Propagation Delay (Maximum): 2.35 ns
Package / Case: 8-SOIC
Mounting Type: Surface Mount
RoHS Status: RoHS Compliant
Key Features
The 8302AMLF is a 1:2 LVCMOS fanout buffer designed to distribute clock signals with minimal delay. It features two outputs, allowing a single input to drive multiple components. With a maximum propagation delay of 2.35 ns, it ensures timely signal distribution, which is crucial in synchronous systems. The device is housed in an 8-SOIC package, facilitating easy integration into various circuit designs. Its surface-mount configuration supports automated assembly processes, enhancing manufacturing efficiency. Additionally, the 8302AMLF is RoHS compliant, reflecting Renesas Electronics’ commitment to environmental standards.
Applications
Clock distribution in digital systems
Timing signal buffering
Data communication equipment
Networking hardware
Industrial automation systems
Product Overview
The 8302AMLF from Renesas Electronics serves as a reliable solution for clock signal buffering and distribution in digital circuits. By providing two LVCMOS outputs from a single input, it enables efficient signal management in complex systems. The device’s low propagation delay of up to 2.35 ns ensures that timing requirements are met, maintaining system synchronization. Its compact 8-SOIC package and surface-mount design allow for seamless integration into space-constrained applications. The RoHS compliance of the 8302AMLF underscores its adherence to environmental regulations, making it a suitable choice for eco-conscious designs.
