AD5780BCPZ Specifications
Manufacturer: Analog Devices
Part Number: AD5780BCPZ
Product Type: Digital to analog converter
Resolution: 18-bit true DAC
Output Type: Unbuffered voltage output
Reference: Buffered precision reference inputs
Interface Type: 3-wire serial compatible (SPI, QSPI, MicroWire, DSP)
Supply Voltage Range: Up to ±16.5 V analog
Operating Temperature Range: −40 °C to +125 °C
Package Type: 24-lead LFCSP
Mounting Type: Surface mount
Settling Time: Typical low microsecond class
Noise Spectral Density: Low noise performance
Linearity: ±1 LSB INL typical
Key Features
The AD5780BCPZ provides high-resolution analog voltage output from digital input codes. Additionally, the part supports true 18-bit accuracy for precise signal generation. Moreover, its buffered reference inputs reduce the need for external buffer components. Furthermore, the versatile serial interface promotes easy integration with standard microcontrollers and DSPs.
Applications
Precision industrial control systems
Test and measurement instruments
Medical instrumentation
Scientific and aerospace data acquisition
Digital gain and offset adjustment
Power supply control circuits
Automated calibration systems
High-accuracy analog signal generation
Product Overview
The Analog Devices AD5780BCPZ is an 18-bit voltage output digital to analog converter designed for high-precision applications requiring low noise and stable performance. Specifically, it offers true 18-bit resolution with excellent linearity, enabling finely controlled analog signal outputs. As a result, designers can implement accurate analog regulation in demanding systems. Moreover, the integrated reference buffers simplify circuit design and reduce external component count. Therefore, overall system complexity is lowered.
In addition, the wide analog supply range supports flexible power architectures and bipolar operation. Furthermore, the DAC’s serial interface is compatible with SPI, QSPI, MICROWIRE and DSP standards, which improves integration with many digital controllers. Consequently, development and prototyping timelines are shortened. Because of its compact LFCSP package, the AD5780BCPZ fits well into space-constrained PCBs. Moreover, surface mount construction enables automated assembly for high volume builds. Therefore, this DAC remains a preferred choice for precision data acquisition and control systems that demand high accuracy and robustness in analog output performance.
