AD9516-1BCPZ

AD9516-1BCPZ

$11.00

IC CLOCK GENERATOR 64LFCSP
  • Manufacturer: Analog Devices Inc
  • Part Number: AD9516-1BCPZ
  • Packaging: Tray
  • Quantity: Each
  • Datecode: 2214

Availability: 21 in stock

SKU TSX054C Category Brand:

AD9516-1BCPZ Specifications

Manufacturer: Analog Devices Inc.
Part Number: AD9516-1BCPZ
Product Type: 14-Output Clock Generator with Integrated 2.5 GHz VCO
Number of Outputs: 14
Maximum Output Frequency: 2.65 GHz
Input Frequency Range: Up to 2.4 GHz
Output Types: 6 LVPECL pairs, 4 LVDS pairs (reconfigurable as 8 CMOS outputs)
Supply Voltage Range: 3.135 V to 3.465 V
Package / Case: 64-lead LFCSP
Mounting Type: Surface Mount
Operating Temperature Range: -40°C to +85°C
RoHS Status: RoHS Compliant

Key Features

The AD9516-1BCPZ delivers precise and flexible clock generation for high-performance systems. It integrates a 2.5 GHz voltage-controlled oscillator, eliminating the need for external VCO components. Furthermore, it supports input frequencies up to 2.4 GHz, which allows designers to match various reference clock sources. This device offers six LVPECL pairs for outputs up to 1.6 GHz and four LVDS pairs that can also be used as eight CMOS outputs. Each output features programmable dividers and delay controls to align timing exactly as required. Because of its low phase noise and jitter, it enhances signal quality in systems with high-speed data converters or communications infrastructure.

Applications

Clock distribution for 10G/40G/100G line cards in SONET and Ethernet systems
Synchronized timing in base stations and radio transceivers
Data converter clocking for precision ADCs and DACs
Reference clock generation in test and measurement instruments
Backplane synchronization in high-end storage and compute platforms

Product Overview

The AD9516-1BCPZ from Analog Devices supports advanced timing solutions across communication, data acquisition, and instrumentation systems. Its integrated VCO simplifies design while supporting frequencies up to 2.65 GHz. Designers can configure each output channel with independent dividers and delays, which improves system-level timing control. Additionally, the device allows flexible output types, such as LVPECL, LVDS, or CMOS, to meet different signal standards. Because it maintains exceptionally low jitter and phase noise, it provides reliable reference signals for high-performance devices. Its compact 64-lead LFCSP package and industrial temperature range ensure seamless integration into robust, space-constrained designs.
