AD9516-4BCPZ

AD9516-4BCPZ Specifications

Manufacturer: Analog Devices Inc.
Part Number: AD9516-4BCPZ
Product Type: Clock Generator and Fanout Distribution IC
Integrated VCO Frequency Range: 1.45 GHz to 1.80 GHz
External VCO/VCXO Frequency Support: Up to 2.4 GHz
Reference Inputs: 1 differential or 2 single-ended
LVPECL Outputs: 6 pairs (up to 1.6 GHz)
LVDS Outputs: 4 pairs (up to 800 MHz)
CMOS Outputs: Each LVDS output can be reconfigured as two 250 MHz CMOS outputs
Output Dividers: LVPECL outputs: 1 to 32; LVDS/CMOS outputs: up to 1024
Additive Output Jitter: LVPECL: 225 fs rms; LVDS: 275 fs rms
Supply Voltage: 3.3 V nominal (supports 2.5 V to 3.3 V for LVPECL)
Package / Case: 64-Lead LFCSP (9 mm × 9 mm)
Mounting Type: Surface Mount
Operating Temperature Range: -40°C to +85°C
RoHS Status: RoHS Compliant

Key Features

The AD9516-4BCPZ is a versatile clock generator and distribution IC designed to deliver low phase noise and jitter performance, essential for high-speed data converter applications. It integrates a voltage-controlled oscillator (VCO) that tunes from 1.45 GHz to 1.80 GHz, with the option to use an external VCO or VCXO up to 2.4 GHz. The device offers flexible output configurations, including six LVPECL output pairs capable of operating up to 1.6 GHz, and four LVDS output pairs that can function up to 800 MHz. Each LVDS output can also be reconfigured as two CMOS outputs, supporting frequencies up to 250 MHz. Programmable output dividers and coarse phase delay adjustments provide precise control over clock distribution, ensuring synchronization across complex systems. The AD9516-4BCPZ’s low additive jitter and phase noise characteristics make it suitable for applications demanding high signal integrity.

Applications

High-speed data communication systems requiring precise clock distribution
Networking equipment demanding low jitter performance
Telecommunication systems with stringent synchronization requirements
Instrumentation and test equipment necessitating accurate timing signals
Wireless communication infrastructure relying on stable clock generation

Product Overview

The AD9516-4BCPZ from Analog Devices Inc. is engineered to meet the rigorous demands of modern high-speed electronic systems. Its integrated VCO and flexible output configurations allow designers to tailor clock signals to specific application needs, enhancing system performance. The device’s ability to accept both differential and single-ended reference inputs adds to its versatility, accommodating various design architectures. With programmable delays and dividers, the AD9516-4BCPZ ensures precise timing alignment, crucial for applications like data converters, where synchronization directly impacts accuracy. Its robust design and wide operating temperature range make it a reliable choice for both commercial and industrial environments. Moreover, the compact 64-lead LFCSP package facilitates efficient PCB layout, saving valuable board space without compromising functionality. The AD9516-4BCPZ exemplifies Analog Devices’ commitment to providing high-performance timing solutions that address the evolving challenges of today’s electronic systems.
