ADF4001BRUZ-R7

ADF4001BRUZ-R7 Specifications

Manufacturer: Analog Devices
Part Number: ADF4001BRUZ-R7
Product Type: Phase-Locked Loop (PLL) Frequency Synthesizer
Input Frequency Range: 10 MHz to 200 MHz
Power Supply Voltage Range: 2.7 V to 5.5 V
Charge Pump Current: Programmable
Reference Divider: Programmable 14-bit counter
N Counter: Programmable 13-bit counter
Phase Frequency Detector (PFD): Low-noise digital
Serial Interface: 3-wire
Power-Down Modes: Hardware and software
Lock Detect: Analog and digital
Package / Case: 16-Lead Thin Shrink Small Outline Package (TSSOP)
Operating Temperature Range: -40°C to +85°C
RoHS Status: RoHS Compliant

Key Features

The ADF4001BRUZ-R7 from Analog Devices is a PLL frequency synthesizer designed to implement clock sources requiring low-noise and stable reference signals. It integrates a low-noise digital phase frequency detector (PFD), a precision charge pump, a programmable 14-bit reference divider, and a programmable 13-bit N counter. The device supports input frequencies ranging from 10 MHz to 200 MHz and operates with a power supply voltage between 2.7 V and 5.5 V. The programmable charge pump currents and counters allow for flexible frequency synthesis. The ADF4001BRUZ-R7 features a 3-wire serial interface for easy communication and offers both hardware and software power-down modes to conserve energy. Additionally, it provides both analog and digital lock detect functions to ensure reliable operation. The device is housed in a compact 16-lead TSSOP package, suitable for space-constrained applications.

Applications

Clock generation in communication systems requiring precise and stable frequency synthesis.
Instrumentation and test equipment needing low-noise clock sources for accurate measurements.
Wireless and wired broadband systems where reliable frequency synthesis is critical.
Industrial automation systems requiring synchronized clock signals for control processes.
Medical imaging equipment demanding stable and low-jitter clock generation.

Product Overview

Analog Devices’ ADF4001BRUZ-R7 is engineered to deliver precise and stable frequency synthesis for applications requiring low-noise clock generation. Its integration of a low-noise digital PFD, precision charge pump, and programmable counters allows for flexible and accurate frequency synthesis. The device’s wide input frequency range and power supply voltage compatibility make it versatile for various applications. The inclusion of both hardware and software power-down modes enhances energy efficiency. Allowing the analog and digital lock detect functions ensure reliable operation. Packaged in a 16-lead TSSOP, the ADF4001BRUZ-R7 is well-suited for designs with limited space, offering a compact yet powerful solution for frequency synthesis needs.
