ADG5208BRUZ Specifications
Manufacturer: Analog Devices
Part Number: ADG5208BRUZ
Device Type: Analog multiplexer
Configuration: 8:1 single-ended multiplexer
Switch Technology: CMOS analog switch
Supply Voltage Range: 4.5 V to 16.5 V single supply
Dual Supply Range: ±4.5 V to ±16.5 V
On Resistance: 200 Ω typical
On Resistance Flatness: 25 Ω typical
Leakage Current: 1 nA typical
Bandwidth: 20 MHz
Package Type: TSSOP-16
Mounting Style: Surface mount
Operating Temperature Range: -40 °C to +85 °C
Logic Interface: TTL and CMOS compatible
Packaging Type: Tube
Key Features
This precision analog multiplexer provides low leakage and stable switching performance across a wide signal range. It supports both single-supply and dual-supply operation, which improves design flexibility. Additionally, the low on resistance flatness helps maintain signal integrity. The CMOS architecture minimizes power consumption during operation. As a result, it performs well in sensitive analog signal paths. Moreover, the compact TSSOP package supports space-constrained PCB designs. Therefore, it integrates easily into mixed-signal systems.
Applications
Data acquisition systems
Signal routing in test equipment
Instrumentation front-end switching
Industrial automation signal selection
Medical monitoring equipment
Process control input multiplexing
Battery-powered measurement devices
Audio and sensor signal routing
Communications test platforms
Product Overview
The ADG5208BRUZ from Analog Devices is designed to deliver accurate and repeatable analog signal switching in precision systems. First, its 8:1 configuration allows efficient channel selection while reducing component count. Additionally, the wide supply voltage range supports both modern low-voltage and legacy bipolar designs. As system accuracy becomes more critical, the low leakage and controlled on resistance help preserve signal fidelity. Furthermore, the device maintains consistent performance over temperature. Consequently, it suits both industrial and instrumentation environments. While optimized for analog accuracy, it remains simple to integrate using standard logic control. Therefore, it supports clean signal routing without added complexity. Overall, this multiplexer balances precision, flexibility, and reliability for demanding analog applications.
