ALC888S-VD2-GR Specifications
Manufacturer: Realtek
Part Number: ALC888S-VD2-GR
Date Code: 2208
Quantity Available: 65 pieces
Product Type: HD Audio Codec
Audio Channels: 7.1+2 Channel
DAC Channels: 10
ADC Channels: 2 Stereo ADCs
Audio Format: 16/20/24-bit PCM
DAC Sample Rate: Up to 192 kHz
ADC Sample Rate: Up to 192 kHz
Digital Audio Support: SPDIF Input and Output
Package Type: 48-Pin LQFP
Package Style: Green Package
Application: PC, embedded, and motherboard audio systems
Key Features
The Realtek ALC888S-VD2-GR is a 7.1+2 channel HD audio codec. It is designed for PC audio, embedded platforms, and motherboard audio designs. In addition, it supports multichannel playback and recording functions in a compact integrated circuit.
This device includes ten DAC channels for 7.1 channel playback and additional independent stereo output support. It also includes two stereo ADCs for recording applications. Therefore, it can support speaker output, microphone input, line input, and related audio functions.
The codec supports 16-bit, 20-bit, and 24-bit PCM audio formats. It also supports sample rates up to 192 kHz. As a result, it can be useful in systems that require integrated HD audio performance with a small 48-pin LQFP package.
Applications
Desktop motherboard audio circuits
Embedded computer audio systems
Industrial PC platforms
Multichannel speaker output designs
Microphone input circuits
Line input and line output circuits
Digital audio interface support
Board-level repair applications
OEM production support
Legacy audio codec replacement
Product Overview
The Realtek ALC888S-VD2-GR is a 7.1+2 channel HD audio codec for PC, embedded, and motherboard audio applications. It supports multichannel sound output, audio recording, and digital audio interface functions. Therefore, it is useful in systems that need integrated audio without a separate sound card.
This codec includes ten DAC channels for 7.1 channel playback. In addition, it supports extra independent stereo output for front-panel or multiple-streaming applications. The device also includes two stereo ADCs for recording functions. These features help support speaker output, microphone input, line input, and line output designs.
The ALC888S-VD2-GR supports 16-bit, 20-bit, and 24-bit PCM audio formats. It also supports DAC and ADC sample rates up to 192 kHz. As a result, it can serve many standard HD audio requirements in computer and embedded hardware.
This part is supplied in a 48-pin LQFP Green package. Because of that, it supports board-level assembly in compact electronic designs. Buyers should confirm the package, pinout, codec configuration, driver support, and board design before purchase.
Cyndtek® supplies audio ICs, semiconductors, electronic components, and hard-to-find parts for OEM, repair, test, and production applications. To request pricing or availability for ALC888S-VD2-GR, visit our Cyndtek shop or contact sales@cyndtek.com with your quantity, target price, and required delivery schedule.
