APT1608CGCK

APT1608CGCK Specifications

Manufacturer: Kingbright
Part Number: APT1608CGCK
Product Type: Surface-Mount LED
Emitting Color: Green
Wavelength – Peak: 574 nm
Wavelength – Dominant: 570 nm
Luminous Intensity: 20 mcd (min), 50 mcd (typ) at 20 mA
Forward Voltage: 2.1 V (typ), 2.5 V (max) at 20 mA
Viewing Angle: 120°
Lens Type: Water Clear
Package Dimensions: 1.6 mm (L) x 0.8 mm (W) x 0.75 mm (H)
Mounting Type: Surface Mount
Operating Temperature Range: -40°C to +85°C
Power Dissipation: 75 mW
Compliance: RoHS Compliant, Halogen-Free

Key Features

The APT1608CGCK is a compact green surface-mount LED designed for low power consumption and high efficiency. Emitting at a dominant wavelength of 570 nm, it delivers a typical luminous intensity of 50 mcd at 20 mA. The LED’s 120° wide viewing angle ensures uniform illumination across applications. Its water-clear lens enhances brightness and color purity. The device’s small footprint, measuring 1.6 mm by 0.8 mm with a height of 0.75 mm, makes it suitable for space-constrained designs. Additionally, the APT1608CGCK is halogen-free and RoHS compliant, aligning with environmental safety standards.

Applications

Backlighting for LCDs, keypads, and symbols
Status indicators in consumer electronics
Wearable devices requiring compact light sources
Healthcare instruments with visual alerts
Portable devices needing energy-efficient illumination

Product Overview

The Kingbright APT1608CGCK is engineered to provide reliable and efficient green light emission in a miniature surface-mount package. Its low power consumption and high luminous intensity make it ideal for various applications, including backlighting and status indication in compact electronic devices. The LED’s wide viewing angle and water-clear lens contribute to consistent and bright illumination. Designed to operate within a temperature range of -40°C to +85°C, it ensures performance stability in diverse environmental conditions. The APT1608CGCK’s compliance with RoHS and halogen-free standards underscores Kingbright’s commitment to environmentally responsible manufacturing.
