AQV252G2SX Specifications
Manufacturer: Panasonic
Part Number: AQV252G2SX
Device Type: Solid state relay
Relay Type: PhotoMOS relay
Output Configuration: 1 Form A normally open
Load Voltage Rating: 60 V AC or DC
Continuous Load Current: 0.5 A
On Resistance: Low on resistance design
Input Control Type: LED drive input
Isolation Voltage: High input to output isolation
Package Type: SOP surface mount package
Mounting Style: Surface mount
Switching Speed: Fast switching response
Operating Temperature Range: -40 °C to +85 °C
Packaging Type: Tape and reel
Category: Semiconductor
Key Features
This PhotoMOS relay provides silent and reliable switching. It eliminates mechanical contact wear. As a result, service life is extended. The optical isolation improves noise immunity. Additionally, the low on resistance reduces power loss. Therefore, efficiency remains stable. The compact SOP package supports dense PCB layouts.
Applications
Automated test equipment switching
Industrial control signal isolation
Telecommunications signal routing
Medical instrumentation switching
Measurement and data acquisition systems
Battery-powered electronic circuits
Consumer electronics control interfaces
Low-voltage signal switching
Product Overview
The AQV252G2SX from Panasonic is designed for dependable solid state switching in compact electronic systems. First, its PhotoMOS structure provides clean, bounce-free operation. This improves signal accuracy. Next, the normally open output supports simple control logic. Because of this, system integration is straightforward.
Additionally, the device offers strong electrical isolation. This helps protect sensitive control circuitry. The fast switching response supports precise timing control. As a result, performance remains consistent. The surface-mount package simplifies automated assembly. Therefore, manufacturing efficiency improves.
Overall, this solid state relay balances reliability and compact size. It fits well in control, test, and measurement designs. Engineers can rely on it where quiet and dependable switching is required.
