ASP-104815-01 Specifications
Manufacturer: Samtec
Part Number: ASP-104815-01
Product Type: High-Density Open-Pin-Field Array Connector
Pitch: 1.27 mm (0.050″)
Number of Positions: Varies by configuration
Contact Type: Edge Rate®
Mounting Type: Surface Mount
Stack Height Range: 7 mm to 18.5 mm
Operating Temperature Range: -55°C to +125°C
RoHS Status: RoHS Compliant
Key Features
The ASP-104815-01 is a high-density, open-pin-field array connector from Samtec’s SEARAY™ series. With a 1.27 mm pitch, it offers flexibility in design and routing for single-ended or differential pair configurations, accommodating power, signal, or ground connections. The connector utilizes Samtec’s Edge Rate® contact system, designed for high mating cycles and optimized signal integrity performance. Its surface mount design supports stack heights ranging from 7 mm to 18.5 mm, providing versatility in board-to-board applications. Engineered to operate within a temperature range of -55°C to +125°C, it ensures reliability in various environmental conditions.
Applications
High-speed board-to-board interconnects
Data communications equipment
Telecommunications
Industrial automation
Medical devices
Product Overview
The ASP-104815-01 connector is part of Samtec’s SEARAY™ series, known for its high-density and high-speed capabilities. The open-pin-field design allows for maximum grounding and routing flexibility, making it suitable for complex and high-performance applications. The Edge Rate® contact system reduces wear during mating cycles, enhancing durability and ensuring consistent performance over time. Its surface mount configuration and adjustable stack height options facilitate seamless integration into various PCB layouts. Compliant with RoHS standards, this connector meets environmental and safety requirements for global applications.
