BAS40W-04-F Specifications
Manufacturer: ON Semiconductor
Part Number: BAS40W-04-F
Device Type: Switching diode pair
Configuration: Dual series connection
Polarity: Silicon
Package Type: SOT-23
Mounting Type: Surface mount
Forward Voltage: Low forward voltage
Reverse Recovery Time: Fast switching
Maximum Reverse Voltage: 40 V
Maximum Forward Current: 200 mA
Junction Capacitance: Low capacitance design
Operating Temperature Range: -55 °C to +150 °C
Key Features
The BAS40W-04-F features two silicon switching diodes in a single SOT-23 package. Additionally, the paired configuration simplifies board layout for dual-path signal routing. Moreover, fast switching performance supports high-speed applications. Furthermore, the low forward voltage characteristic improves efficiency in switching circuits.
Applications
High-frequency switching applications
Signal steering and routing
Logic level translation
Clamp and protection circuits
High-speed digital circuits
RF front-end design
Communication interface protection
General-purpose diode requirements
Product Overview
The ON Semiconductor BAS40W-04-F is a dual silicon switching diode designed for efficient signal control in compact surface mount applications. Specifically, the dual series configuration allows two diodes in one SOT-23 package, which reduces board footprint. As a result, designers can save space in high-density layouts. Additionally, the diode pair supports fast switching operation, which enhances overall circuit responsiveness. Moreover, the low forward voltage characteristic improves efficiency by minimizing voltage drop during conduction. Therefore, this part suits high-speed switching and logic pathways.
In addition, the low junction capacitance supports use in high-frequency environments. Furthermore, the compact surface mount package enables automated assembly and high-volume manufacturing. Consequently, design and production become more streamlined. Because of its robust performance, the BAS40W-04-F also supports protection and steering functions in communication circuits. Overall, this dual diode delivers space-efficient switching with reliable electrical performance for a wide range of applications.
