CGA3E2X7R1H223K080AA Specifications
Manufacturer: TDK
Part Number: CGA3E2X7R1H223K080AA
Product Type: Multilayer Ceramic Capacitor
Capacitance: 0.022 µF
Voltage Rating: 50 V
Capacitance Tolerance: ±10%
Dielectric Type: X7R
Package Size: 0603 SMD
Mounting Type: Surface Mount
Temperature Characteristics: X7R Stable Dielectric
Operating Temperature Range: -55°C to +125°C
Construction: Multilayer Ceramic
Termination Finish: Nickel Barrier with Tin
Applications Class: General Purpose Electronics
Packaging: Factory
Key Features
The CGA3E2X7R1H223K080AA is a multilayer ceramic capacitor designed for reliable decoupling and filtering in compact electronic circuits. It provides a capacitance value of 0.022 µF with a 50 volt rating and ±10% tolerance. Additionally, the X7R dielectric maintains stable capacitance across a wide temperature range. Because the capacitor uses a compact 0603 surface mount package, it supports dense circuit layouts used in modern electronic assemblies. As a result, engineers frequently integrate this component into power management and signal conditioning circuits.
Applications
Power supply decoupling circuits
DC-DC converter input filtering
Microcontroller power stabilization
Signal coupling networks
Industrial control electronics
Consumer electronic circuit boards
Embedded system power filtering
Communication equipment electronics
Product Overview
The CGA3E2X7R1H223K080AA capacitor from TDK supports modern electronic designs that require reliable capacitance in a compact footprint. First, the multilayer ceramic construction provides stable electrical performance and dependable long-term operation.
Additionally, the X7R dielectric allows the capacitor to maintain useful capacitance across a wide operating temperature range. Because electronic systems often experience temperature variation during operation, this stability helps maintain consistent circuit performance.
Moreover, the 0603 surface mount package allows designers to place capacitors close to integrated circuits and power devices. This placement improves decoupling efficiency and helps stabilize voltage rails.
Therefore, engineers commonly use the CGA3E2X7R1H223K080AA in digital electronics, embedded controllers, and communication hardware that require dependable filtering and decoupling performance.
