DF19G-30P-1H(52) Specifications
Manufacturer: Hirose Electric
Part Number: DF19G-30P-1H(52)
Date Code: 2410
Quantity Available: 40 pieces
Product Type: Connector Header
Connector Series: DF19
Connector Style: Right-Angle Pin Header
Mounting Style: Surface Mount
Number of Positions: 30
Number of Rows: 1
Pitch: 1.00 mm
Height Above Board: 1.65 mm
Packaging: Tape and Reel
Application: Board-level signal and wire-to-board interconnect
Key Features
The Hirose DF19G-30P-1H(52) is a 30-position right-angle SMT header. It is part of the DF19 Series. In addition, the 1.00 mm pitch supports compact board-level connections.
This connector uses a single-row layout and a right-angle mounting style. As a result, it helps route connections parallel to the circuit board. The surface-mount design also supports automated assembly and compact PCB layouts.
The low-profile design provides a 1.65 mm height above the board. Therefore, it can work well in slim electronic assemblies. It is useful where space is limited and a small right-angle connector is required.
Applications
Portable electronic equipment
Compact PCB assemblies
Board-level signal connections
Wire-to-board interconnects
Industrial control boards
Embedded computing systems
Medical electronic devices
Communication equipment
Test and measurement hardware
Repair and replacement applications
Product Overview
The Hirose DF19G-30P-1H(52) is a DF19 Series connector header. It provides 30 positions in a compact 1.00 mm pitch layout. Therefore, it supports dense board-level interconnect designs.
This part uses a right-angle surface-mount configuration. In addition, the connector helps route signals parallel to the printed circuit board. This can be useful in low-profile devices, compact modules, and assemblies with limited vertical space.
The single-row layout supports straightforward board routing and mating connector alignment. Also, the low height above the board helps reduce the finished assembly profile. As a result, the DF19G-30P-1H(52) can support portable electronics, embedded systems, control boards, and communication hardware.
Because connector applications can vary, buyers should confirm pitch, position count, orientation, footprint, mating connector, and assembly process before purchase. Matching the correct Hirose DF19 Series part number can help avoid fit, alignment, and mating issues.
Cyndtek® supplies connectors, electronic components, and hard-to-find parts for production, repair, replacement, and system support requirements. To request pricing or availability for DF19G-30P-1H(52), visit our Cyndtek shop or contact sales@cyndtek.com with your quantity, target price, and required delivery schedule.
