DS80PCI810NJYT

DS80PCI810NJYT

$6.00

IC REDRIVER PCIE 8CHAN 54WQFN 2.5/5.0/8.0-Gbps
  • Manufacturer: TI
  • Part Number: DS80PCI810NJYT
  • Packaging:
  • Quantity: Each
  • Datecode:

Availability: 98 in stock

SKU TSX009A Category Brand:

DS80PCI810NJYT Specifications

Manufacturer: Texas Instruments
Part Number: DS80PCI810NJYT
Product Type: PCI Express Repeater / Redriver
Data Rate: Up to 8.0 Gbps
Channels: 1
Input Type: Differential
Output Type: Differential
Supply Voltage: 3.3V
Power Consumption: 330 mW (typical)
Equalization: Adaptive
De-emphasis: Adjustable
Package / Case: 24-WQFN (4mm x 4mm)
Mounting Type: Surface Mount
Operating Temperature Range: -40°C to +85°C
Compliance: PCIe Gen3, SATA 6Gbps, SAS-2
RoHS Status: RoHS Compliant

Key Features

The DS80PCI810NJYT is a high-speed signal redriver from Texas Instruments that supports data rates up to 8.0 Gbps. It is designed for PCIe Gen3, SATA, and SAS interconnects. With one differential channel, it enables signal restoration in high-speed layouts where attenuation or noise may degrade performance. Adaptive equalization and programmable de-emphasis ensure clean signal integrity across varying trace lengths and board conditions. Its compact WQFN package makes it ideal for space-constrained applications.

Applications

PCIe Gen3 links in computing systems
SATA and SAS storage interconnects
Backplane and cable extension
High-speed data transmission in industrial equipment
Signal integrity enhancement in embedded platforms
Networking and communication systems

Product Overview

The DS80PCI810NJYT from Texas Instruments provides a robust solution for maintaining signal quality in high-speed data channels. It supports 8.0 Gbps transmission and complies with PCIe Gen3, SATA 6Gbps, and SAS-2 standards. With adaptive equalization, it compensates for signal loss without user intervention. Moreover, adjustable de-emphasis allows for fine-tuning in longer trace environments. Because of its low power consumption and compact 24-WQFN package, it integrates easily into modern, dense PCB layouts. The redriver operates reliably from -40°C to +85°C, making it suitable for both commercial and industrial environments. For designs needing clean high-speed signaling with minimal power and board space, the DS80PCI810NJYT is a reliable choice.
