EC2630QI

EC2630QI Specifications:

• Manufacturer: Intel (formerly Altera)
• Series: Enpirion®
• Type: Intermediate Voltage Bus Converter
• Input Voltage: 8V to 13.2V
• Output Voltage: Fixed at half the input voltage (Vin/2)
• Output Current: Up to 4.5A
• Power Output: Up to 27W
• Switching Frequency: 115kHz
• Operating Temperature Range: -40°C to +85°C
• Package / Case: 36-VFQFN Exposed Pad (5mm x 5mm)
• Mounting Type: Surface Mount
• Status: Obsolete

Description:

The EC2630QI is a highly efficient DC-DC intermediate voltage bus converter from Intel’s Enpirion® series, designed to provide reliable power conversion in a compact, surface-mount package. This part takes an input voltage range from 8V to 13.2V and converts it into a fixed output voltage that is half the input voltage (Vin/2). This makes the EC2630QI ideal for applications requiring intermediate voltage levels, such as powering multiple lower-voltage converters or sensitive components in communication systems.

With an output current capability of up to 4.5A and a power output of up to 27W, this converter is suitable for a wide range of industrial, telecommunications, and automotive applications. Its efficient power conversion reduces the need for additional stages of voltage regulation, leading to a more streamlined power supply design and a reduction in the overall footprint on the PCB.

The EC2630QI operates with a switching frequency of 115kHz, providing stable performance across a wide temperature range of -40°C to +85°C. Housed in a compact 36-VFQFN exposed pad package measuring 5mm x 5mm, it is designed for surface mount installation, ensuring ease of integration into modern electronic systems.

However, it is important to note that the EC2630QI is now considered obsolete, so availability may be limited. Despite this, its reliable performance in power conversion applications remains noteworthy for those working with older systems or requiring specific power solutions.
