EEF-GX0E471R Specifications
Manufacturer: Panasonic
Part Number: EEF-GX0E471R
Product Type: Conductive Polymer Aluminum Electrolytic Capacitor (SP-Cap)
Capacitance: 470 µF
Rated Voltage: 2.5 V DC
Capacitance Tolerance: ±20%
Equivalent Series Resistance (ESR): 3 mΩ (maximum) at 100 kHz
Leakage Current: ≤117.5 µA after 2 minutes at rated voltage
Dissipation Factor (tan δ): 6% (maximum)
Rated Ripple Current: 10.2 A at 100 kHz
Operating Temperature Range: -55°C to +105°C
Endurance: 2,000 hours at 105°C with rated voltage applied
Case Size: 7.3 mm (L) x 4.3 mm (W) x 1.9 mm (H)
Mounting Type: Surface Mount
RoHS Status: RoHS Compliant
Key Features
The EEF-GX0E471R from Panasonic is a surface-mount conductive polymer aluminum electrolytic capacitor, part of the SP-Cap series, designed for high-performance applications requiring low ESR and high ripple current capability. With a capacitance of 470 µF and a rated voltage of 2.5 V DC, this capacitor offers an exceptionally low ESR of 3 mΩ at 100 kHz, enabling efficient performance in high-frequency circuits. It supports a high ripple current of 10.2 A at 100 kHz, ensuring reliability under demanding conditions. The capacitor’s compact dimensions (7.3 mm x 4.3 mm x 1.9 mm) facilitate space-saving designs, making it suitable for high-density circuit boards. Additionally, it boasts an endurance of 2,000 hours at 105°C with rated voltage applied, highlighting its durability in prolonged operations.
Applications
Power supply circuits in telecommunications equipment requiring stable voltage regulation.
Decoupling and smoothing applications in computer motherboards and graphic cards.
Input and output filtering in DC-DC converters for industrial automation systems.
Bypass capacitors in audio amplifiers to ensure clean signal processing.
Energy storage in portable medical devices where reliability is critical.
Product Overview
Panasonic’s EEF-GX0E471R is engineered to deliver exceptional performance in applications demanding low ESR and high capacitance stability. Its conductive polymer aluminum construction ensures minimal leakage current and robust thermal characteristics. Thus making it ideal for high-frequency and high-temperature environments. The capacitor’s compact surface-mount design allows for efficient use of PCB space, while its compliance with RoHS standards underscores its environmental friendliness. With a wide operating temperature range and substantial endurance rating, the EEF-GX0E471R stands out as a reliable choice for designers seeking efficiency and longevity in their electronic components.
