EG2207 Specifications
Manufacturer: E-Switch
Part Number: EG2207
Device Type: Toggle switch
Switch Function: On-On configuration
Number of Poles: DPDT
Mounting Style: Panel mount
Termination Style: Solder lug terminals
Actuator Type: Bat handle
Actuator Material: Metal
Contact Material: Silver alloy
Contact Rating: Suitable for low-voltage and signal switching
Electrical Life: Long mechanical cycle life design
Mounting Hole Diameter: Standard round panel cutout
Operating Temperature Range: Industrial temperature range
Packaging Type: Bulk
Category: Hardware
Key Features
This DPDT toggle switch provides dependable manual control. It supports an On-On circuit configuration. As a result, it suits signal routing and control tasks. The metal bat actuator offers tactile feedback. Additionally, the panel-mount design ensures secure installation. The silver alloy contacts support stable electrical performance. Therefore, switching remains consistent over repeated use. The solder lug terminals simplify wiring during assembly.
Applications
Industrial control panels
Instrumentation and test equipment
Power and signal routing assemblies
Audio and communications equipment
Custom control enclosures
Laboratory and bench equipment
OEM control interfaces
Product Overview
The EG2207 from E-Switch is designed for reliable panel-mounted switching in control and instrumentation systems. First, its DPDT configuration allows flexible circuit control. This supports signal selection and polarity switching. Next, the On-On action provides stable position control without a center-off state. Because of this, operators can switch between two active circuits with confidence.
Additionally, the metal bat handle improves durability in frequent-use environments. It also delivers clear tactile response during operation. The panel-mount construction helps secure the switch against vibration. As a result, it performs well in industrial enclosures. The solder lug terminals allow straightforward wiring. Therefore, installation time remains efficient.
Overall, this toggle switch balances durability and ease of use. It fits well in both commercial and industrial designs. Engineers and technicians can rely on it for dependable manual control where consistent switching matters.
