EN6310QI

EN6310QI Specifications

Manufacturer: Intel (formerly Altera)
Part Number: EN6310QI
Product Type: 1A PowerSoC Step-Down DC-DC Switching Converter with Integrated Inductor
Input Voltage Range: 2.7V to 5.5V
Output Voltage Range: 0.6V to 3.3V
Maximum Output Current: 1A
Switching Frequency: 4 MHz
Efficiency: Up to 93%
Control Features: Voltage Mode Control
Protection Features: Overcurrent Protection, Thermal Shutdown
Package / Case: 30-pin QFN (4mm x 5mm)
Mounting Type: Surface Mount
Operating Temperature Range: -40°C to +85°C
RoHS Status: RoHS Compliant

Key Features

The EN6310QI is a compact, high-efficiency step-down converter that integrates a 1A power stage and inductor. It supports input voltages from 2.7V to 5.5V and provides an adjustable output between 0.6V and 3.3V. Thanks to its fixed 4 MHz switching frequency, the design allows for very small external components. This helps reduce board space and simplifies layout. Additionally, its voltage mode control maintains stable output even under changing loads. Built-in protection features like thermal shutdown and overcurrent protection increase overall reliability. The small QFN package makes it easy to integrate into tight PCB spaces.

Applications

Point-of-load regulation for low-power processors, FPGAs, and ASICs
Portable and handheld devices
Consumer electronics
Networking and communication equipment
Industrial automation systems
Test and measurement instruments

Product Overview

The EN6310QI delivers efficient point-of-load power conversion in a highly integrated form. It simplifies design by including an onboard inductor and minimizing external parts. Furthermore, its compact size makes it ideal for space-constrained systems. With efficiency up to 93%, the device reduces power loss and heat buildup. It uses voltage mode control for fast, stable performance. Additionally, onboard safeguards protect against overheating and current faults. As a result, the EN6310QI offers a robust solution for modern applications that require efficient, compact power delivery.
