FA-128 24.0000MF10Z-W3

FA-128 24.0000MF10Z-W3 Specifications

Manufacturer: Epson
Part Number: FA-128 24.0000MF10Z-W3
Product Type: Surface-Mount Crystal Unit
Frequency: 24.0000 MHz
Frequency Tolerance: ±10 ppm at 25°C
Stability Frequency : ±10 ppm over -20°C to +75°C
Load Capacitance: 12 pF
Equivalent Series Resistance (ESR): 80 Ω maximum
Operating Mode: Fundamental
Operating Temperature Range: -20°C to +75°C
Storage Temperature Range: -40°C to +125°C
Drive Level: 100 µW maximum (recommended: 1 to 100 µW)
Aging: ±1 ppm/year maximum at 25°C
Package Dimensions: 2.0 mm (L) x 1.6 mm (W) x 0.5 mm (H)
Mounting Type: Surface Mount
RoHS Status: RoHS Compliant

Key Features

The FA-128 24.0000MF10Z-W3 from Epson is a compact surface-mount crystal unit designed for precise frequency control in electronic circuits. Operating at 24.0000 MHz with a frequency tolerance of ±10 ppm at 25°C, it ensures accurate timing essential for high-performance applications. Its frequency stability of ±10 ppm over a temperature range of -20°C to +75°C allows consistent operation under varying environmental conditions. The crystal’s low ESR of 80 Ω enhances energy efficiency, while its fundamental mode operation contributes to reliable performance. Additionally, the small package dimensions of 2.0 mm x 1.6 mm x 0.5 mm facilitate integration into space-constrained designs.

Applications

Clock generation in microcontrollers for consumer electronics
Timing reference in wireless communication modules such as Bluetooth and Wi-Fi
Frequency stabilization in industrial automation equipment
Synchronization in audio-visual devices like digital cameras and camcorders
Precision timing in GPS receivers for accurate location tracking

Product Overview

Epson’s FA-128 24.0000MF10Z-W3 crystal unit offers a reliable solution for applications requiring precise frequency control within a compact form factor. Its tight frequency tolerance and stability ensure accurate timing across various operating conditions. Thus making it suitable for a wide range of electronic devices. The low ESR and fundamental mode operation contribute to efficient performance, while the miniature package supports high-density PCB layouts. Compliance with RoHS standards reflects Epson’s commitment to environmental responsibility, ensuring the crystal unit meets global regulatory requirements.
