G3VM-21LR10(TR05) Specifications
Manufacturer: Omron Electronics
Product Category: Solid State Relay (SSR)
Contact Form: SPST-NO
Maximum Load Voltage: 60 V AC/DC
Continuous Load Current: 1 A
On-State Resistance (Max): 0.3 Ω
Input LED Forward Voltage (Typ): 1.2 V
Isolation Voltage (I/O): 500 Vrms
Switching Time: Fast response suitable for signal switching
Operating Temperature Range: –40 °C to +85 °C
Package / Case: USOP-4 surface mount
Mounting Type: Surface Mount (SMT)
Category: Semiconductor
Key Features:
Additionally, the G3VM-21LR10(TR05) is a MOSFET-based solid state relay that switches low-voltage loads with precision and reliability. Moreover, it offers low on-state resistance to minimize power loss during operation. Furthermore, its high isolation rating helps protect sensitive circuits. Also, the surface mount package supports compact, automated assembly. Finally, the fast switching characteristic enhances performance in data and signal applications.
Applications:
Industrial signal switching
Control systems and automation
Telecommunications equipment
Test and measurement modules
Consumer electronic controls
Product Overview:
The G3VM-21LR10(TR05) solid state relay from Omron Electronics is engineered to deliver reliable low-voltage switching in compact surface mount format. Consequently, its SPST-NO configuration simplifies control circuit design while supporting up to 1 A load current. In addition, the device integrates MOSFET output stages that reduce on-state resistance and improve efficiency. Furthermore, high isolation between input and output ensures robust performance in sensitive systems. As a result, this SSR suits industrial controls, communications gear, and automated measurement systems. Also, its broad operating temperature range makes it adaptable to varied environments. Thus, engineers can trust this component for consistent switching where mechanical relays cannot meet speed or longevity requirements.
