HTSW-106-07-S-D Specifications
Manufacturer: Samtec
Part Number: HTSW-106-07-S-D
Connector Type: High temperature socket strip
Contact Style: Socket
Number of Positions: 12 positions
Number of Rows: 2 rows
Pitch: 2.54 mm
Row Spacing: 2.54 mm
Orientation: Straight
Termination Style: Through-hole
Mounting Type: PCB mount
Contact Material: Phosphor bronze
Contact Plating: Tin over nickel
Insulation Material: High temperature plastic
Operating Temperature Range: -55 °C to +125 °C
Key Features
The HTSW-106-07-S-D is designed for reliable board-to-board connections in demanding environments. Additionally, its high temperature housing supports automated soldering processes. The dual-row layout increases circuit density while maintaining standard 2.54 mm spacing. Furthermore, Samtec’s socket contact design ensures consistent mating force and dependable electrical performance over repeated cycles.
Applications
Industrial control boards
Embedded computing modules
Power management PCBs
Factory automation controllers
Test and measurement equipment
Telecommunications infrastructure
Motor drive control boards
High-reliability prototyping systems
Product Overview
The Samtec HTSW-106-07-S-D socket strip provides a dependable interconnect solution for through-hole PCB designs. Specifically, it supports dual-row configurations that maximize signal routing without increasing board size. As a result, designers can maintain compact layouts while improving system flexibility. Moreover, the connector’s high temperature plastic housing allows it to withstand elevated soldering temperatures. Therefore, it integrates well into modern assembly processes, including wave soldering. Its straight orientation also simplifies vertical board stacking and connector alignment. In addition, the phosphor bronze contacts deliver stable electrical conductivity and mechanical durability. Consequently, this connector performs reliably in environments exposed to vibration or thermal cycling. The tin over nickel plating further enhances solderability while protecting against corrosion. Because of its standardized 2.54 mm pitch, the HTSW-106-07-S-D is compatible with a wide range of mating headers. This compatibility allows engineers to design modular systems with reduced redesign effort. Furthermore, the dual-row format supports higher pin counts in compact footprints. Overall, this connector is well suited for industrial, embedded, and control applications requiring long-term reliability. By combining mechanical strength with thermal resilience, it supports both prototype development and full-scale production. Therefore, it remains a practical choice for engineers seeking proven Samtec interconnect quality.
