HTSW-115-08-G-D Specifications
Manufacturer: Samtec
Part Number: HTSW-115-08-G-D
Connector Type: High temperature socket strip
Contact Style: Socket
Number of Positions: 16 positions
Number of Rows: 2 rows
Pitch: 2.54 mm
Row Spacing: 2.54 mm
Orientation: Straight
Termination Style: Through-hole
Mounting Type: PCB mount
Contact Material: Phosphor bronze
Contact Plating: Gold over nickel
Insulation Material: High temperature plastic
Operating Temperature Range: -55 °C to +125 °C
Key Features
The HTSW-115-08-G-D provides a dependable interconnect solution for dual-row PCB designs. Additionally, the gold-plated contacts enhance conductivity and corrosion resistance. Moreover, the high temperature plastic housing supports automated soldering processes. Furthermore, the socket contact design ensures consistent mating force over repeated cycles.
Applications
Industrial control boards
Embedded computing modules
Power management PCBs
Factory automation controllers
Test and measurement equipment
Telecommunications infrastructure
Motor drive control boards
High-reliability prototyping systems
Product Overview
The Samtec HTSW-115-08-G-D socket strip offers a reliable board-to-board connection solution for through-hole PCB mounting. Specifically, it supports dual-row configurations that help maximize signal routing without increasing board size. As a result, designers can achieve compact layouts while maintaining robust performance. Moreover, the gold-plated phosphor bronze contacts deliver excellent electrical conductivity and enhanced corrosion protection. Therefore, this socket strip performs well in environments requiring repeated mating cycles.
In addition, the high temperature plastic housing withstands elevated soldering temperatures and supports automated assembly processes. Furthermore, the straight orientation simplifies vertical board stacking and alignment. Consequently, the HTSW-115-08-G-D fits effectively into high-density system designs. Because of this, engineers can rely on its mechanical durability and long-term performance.
Overall, this connector delivers high reliability, thermal resilience, and dependable electrical contact. Therefore, it is well suited for industrial, embedded, and control applications requiring robust interconnect solutions.
Contact Us
For pricing, lead time, and technical assistance, Cyndtek is ready to help. Moreover, our team supports OEMs, CMs, and engineers with dependable component solutions. Please contact us today to discuss availability.
