Samtec IPL1‑106‑01‑L‑S‑RA‑K Specifications
Manufacturer: Samtec
Product Category: Connector
Connector Type: Shrouded Right-Angle Header
Series: Mini Mate® IPL1
Number of Contacts: 6 positions
Pitch: 0.100″ (2.54 mm)
Rows: 1 row
Contact Material: Phosphor bronze
Contact Plating: Gold-plated mating area, tin-plated posts
Mounting Style: Through-Hole, Right-Angle
Insulation Material: Liquid crystal polymer
Operating Temperature Range: −55 °C to +125 °C
Termination Style: Solder post
Category: Connector
Key Features:
Moreover, the IPL1-106-01-L-S-RA-K is a compact, shrouded header designed for reliable board-to-wire or board-to-board connections. Additionally, its 0.100″ (2.54 mm) pitch supports standard spacing in many systems. Also, individually shrouded contacts help guide mating connectors and reduce miscoupling. Furthermore, right-angle orientation saves board space and supports flexible layout design. Finally, robust through-hole terminations provide good mechanical strength for repeated insertion and soldering.
Applications:
Embedded system interconnect headers
Low-density signal cabling interfaces
Industrial control PCB headers
Networking module board connections
Test fixture and prototype headers
Product Overview:
The IPL1-106-01-L-S-RA-K from Samtec is a durable and versatile right-angle shrouded header in the Mini Mate® IPL1 family. Consequently, its standard 0.100″ pitch and 6-position layout make it suitable for a wide range of connector applications. Also, gold-plated contacts ensure consistent electrical connections while resisting corrosion. Furthermore, the phosphor bronze and liquid crystal polymer materials support long-term reliability across a broad temperature range. Additionally, the right-angle orientation helps designers optimize board layouts where vertical space is limited. Therefore, this header is ideal for embedded systems, industrial modules, and connectivity interfaces that require dependable mechanical and electrical performance. Moreover, its simple yet robust design fits well in prototype builds and production environments alike.
Contact Us:
For pricing, availability, or technical assistance with IPL1-106-01-L-S-RA-K, email Cyndtek’s sales team at sales@cyndtek.com and we will help with your design and sourcing needs.
For additional available stock, browse our full inventory.
