JPD113D-LBA21-7H Specifications
Manufacturer: Foxconn
Part Number: JPD113D-LBA21-7H
Connector Type: Board-to-board mezzanine connector
Number of Positions: 113 positions
Pitch Spacing: 0.50 mm
Mounting Style: Surface mount
Contact Type: Female contacts
Termination Method: Solder reflow
Orientation: Vertical mating
Housing Material: High-temperature thermoplastic
Contact Material: Copper alloy
Plating: Gold-plated explained contact area
Operating Temperature Range: -40 °C to +85 °C
Voltage Rating: 50 V
Current Rating: 0.5 A per contact
Packaging Type: Tape and reel
Key Features
This high-density mezzanine connector is engineered for compact PCB stacking applications. It supports reliable signal transmission through fine-pitch contact alignment. Additionally, the gold-plated contacts improve conductivity and reduce long-term wear. The surface-mount design allows automated assembly and repeatable solder performance. As a result, it integrates well into modern high-speed electronics. Moreover, the high-temperature housing withstands standard lead-free reflow processes. Therefore, it supports consistent manufacturing outcomes in volume production.
Applications
Embedded computing modules
Industrial controller backplanes
Networking equipment daughtercards
Telecommunications interface boards
Consumer electronics mainboards
Medical device control assemblies
Test and measurement platforms
Automation system PCB stacks
Compact power management modules
Product Overview
The JPD113D-LBA21-7H mezzanine connector from Foxconn delivers a dependable interconnect solution for high-density board-to-board designs. First, its 0.50 mm pitch supports compact layouts where space is limited. Additionally, the vertical mating configuration enables efficient PCB stacking without excessive board spacing. As systems demand higher signal density, this connector maintains stable electrical performance across all contacts. Furthermore, the gold-plated interface enhances signal integrity over repeated mating cycles. Consequently, it is well suited for long-life electronic assemblies. While designed for precision, it remains compatible with standard SMT assembly workflows. Therefore, it supports both performance and manufacturability. Overall, this connector balances density, durability, and electrical consistency in advanced electronic systems.
