LMH0346SQ/NOPB Specifications
- Manufacturer: Texas Instruments
- Product Type: Video ICs
- Series: LMH0346
- Type: Reclocker
- Data Rate: Up to 3 Gbps
- Operating Supply Voltage: 3.3V
- Operating Supply Current: 111 mA
- Power Dissipation: 370 mW
- Moisture Sensitivity: Yes
- Operating Temperature Range: -40°C to +85°C
- Mounting Style: Surface Mount (SMD/SMT)
- Package / Case: WQFN-24
- Packaging: Reel, Cut Tape, MouseReel
- RoHS Compliance: Yes
- Unit Weight: 0.001411 oz
Product Overview
The LMH0346SQ/NOPB is a 3 Gbps HD/SD SDI Reclocker designed for high-speed serial digital video data transmission. It ensures compliance with SMPTE 424M, SMPTE 292M, and SMPTE 259M (C) Standards, making it ideal for broadcast and professional video applications.
Key Features:
- Multi-Rate Support: Handles data rates of 270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.967 Gbps, and 2.97 Gbps, including DVB-ASI at 270 Mbps.
- Automatic Rate Detection: Adjusts to incoming data rates and suppresses accumulated jitter for superior signal integrity.
- Dual Differential Outputs: Offers two reclocked outputs or an alternative low-jitter differential clock output.
- Control & Indicator Functions: Includes manual/auto rate selection, SD/HD operating rate indicator, lock detect output, and mute function for flexible system integration.
- Differential & LVCMOS Compatibility: Features LVPECL-compatible serial data inputs and outputs with LVCMOS control and indicator outputs for easy interfacing.
Applications:
- Broadcast & Professional Video Equipment
- SDTV/HDTV & 3 Gbps Serial Digital Video Interfaces
- Digital Video Routers & Switchers
- Video Processing & Editing Equipment
- DVB-ASI Equipment
- Video Standards & Format Converters
