LPAF-10-03.0-L-04-1-K
Specifications
Manufacturer: Samtec
Part Number: LPAF-10-03.0-L-04-1-K
Product Type: Wire-to-Board/Board-to-Wire Connector
Connector Style: Plug / Receptacle system
Number of Positions: 10 positions
Pitch: 3.00 mm
Orientation: Right-angle
Contact Termination: Crimp or press-fit style contacts
Mounting Type: Through-hole and wire harness connection
Contact Material: High-conductivity copper alloy
Contact Plating: Selective gold plating for signal integrity
Housing Material: High-performance thermoplastic
Color: Natural/black (varies by series)
Operating Temperature Range: Typical industrial range
Key Features
The LPAF-10-03.0-L-04-1-K from Samtec provides a reliable wire-to-board/board-to-wire mating system with a 3.00 mm pitch. Additionally, its right-angle orientation supports flexible harness routing and board placement. Moreover, the 10-position configuration simplifies multi-signal connections. Furthermore, gold plating on critical contact surfaces enhances electrical performance and corrosion resistance.
Applications
Industrial control wiring harnesses
Embedded system power and signal connections
Automation equipment cabling
Telecommunications interface links
Consumer electronics wire harness solutions
Test and measurement interconnects
Power interconnect distribution modules
General-purpose PCB and harness assembly
Product Overview
Samtec’s connector system is designed for dependable wire-to-board and board-to-wire interconnects in industrial and commercial electronics. Specifically, it offers a 10-position design with a standard 3.00 mm pitch that balances density with ease of assembly. As a result, designers can implement multiple signal paths or harness routes with consistent contact reliability. Moreover, the right-angle configuration provides flexibility in harness orientation and PCB layout planning. Therefore, board real estate can be used efficiently in tight mechanical environments.
In addition, the connector’s high-conductivity contact materials and selective gold plating help maintain strong signal integrity, even in systems that undergo repeated mating cycles. Furthermore, the robust thermoplastic housing supports mechanical durability and thermal stability. Consequently, this Samtec connector integrates well into applications requiring both signal and power interconnections that must withstand handling and environmental stress. Because of its quality construction and reliable performance, the LPAF-10-03.0-L-04-1-K-TR remains suitable for a wide range of electronic interconnect needs.
