LTC3850EGN#TRPBF Specifications
Manufacturer: Linear Technology
Part Number: LTC3850EGN#TRPBF
Product Type: Dual, 2-Phase Synchronous Step-Down Switching Controller
Input Voltage Range: 4V to 24V (30V for LTC3850I)
Output Voltage Accuracy: ±1% at 0.8V
Switching Frequency: 250kHz to 780kHz (Phase-Lockable)
MOSFET Drive: Dual N-Channel Synchronous
Current Sensing: Supports RSENSE or DCR
Package / Case: 28-Lead SSOP (0.154″, 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature Range: -40°C to +85°C
RoHS Status: RoHS Compliant
Key Features
The LTC3850EGN#TRPBF is a high-efficiency, dual-phase synchronous step-down switching controller from Linear Technology. It drives all N-channel power MOSFET stages and operates with a constant-frequency current mode control architecture. The two output stages function out of phase, reducing input ripple and power supply noise. Its wide input voltage range of 4V to 24V (30V for the LTC3850I) supports various battery and bus voltage systems.
This controller features OPTI-LOOP® compensation, allowing for optimized transient response across different output capacitances and ESR values. The precision 0.8V reference ensures ±1% output accuracy, while the integrated power good output indicator provides system monitoring. Additionally, the switching frequency can be locked to an external clock up to 780kHz, giving designers flexibility in power system optimization.
Applications
Notebook and palmtop computers
Portable instruments
Battery-operated digital devices
DC power distribution systems
Product Overview
The LTC3850EGN#TRPBF from Linear Technology is designed for high-performance power management in space-efficient applications. Its dual 2-phase synchronous step-down topology minimizes input capacitance requirements and reduces power supply noise. The ability to track external voltage references, along with adjustable soft-start and foldback current limiting, enhances its versatility in complex power regulation designs.
Its combination of high accuracy, wide input range, and adaptive compensation makes it well-suited for battery-powered applications and digital power distribution systems. The controller’s robust feature set ensures stable and efficient power conversion across a wide range of operating conditions, making it an excellent choice for designers requiring reliable voltage regulation.
