LTM4602EV#PBF

LTM4602EV#PBF Specifications

Manufacturer: Analog Devices Inc.
Part Number: LTM4602EV#PBF
Product Type: DC/DC µModule Regulator
Input Voltage Range: 4.5V to 20V
Output Voltage Range: 0.6V to 5V
Output Current: 6A continuous, 8A peak
Efficiency: Up to 92%
Switching Frequency: Adjustable, default at 1.3MHz
Package / Case: 15mm × 15mm × 2.8mm LGA
Mounting Type: Surface Mount
Operating Temperature Range: -40°C to +85°C
RoHS Status: RoHS Compliant

Key Features

The LTM4602EV#PBF is a highly integrated step-down regulator designed for space-limited, high-performance systems. It includes a complete power solution with an internal controller, power FETs, inductor, and supporting components. Because of its efficient layout, the module delivers 6A of continuous output current and handles 8A peak without the need for airflow or heat sinks. It operates over a wide input voltage range from 4.5V to 20V and supports outputs from 0.6V to 5V. Furthermore, the device uses an adaptive on-time control architecture, which provides fast transient response and excellent load regulation. Designers can easily adjust switching frequency and soft-start timing to meet specific system requirements. Its low profile makes it well suited for mounting on the underside of circuit boards, saving space without compromising power.

Applications

Telecom systems requiring efficient power modules in confined spaces
Server hardware that depends on low-profile, high-current regulators
Industrial platforms such as test, control, and automation equipment
Compact point-of-load power systems in FPGA or processor-based designs

Product Overview

The LTM4602EV#PBF from Analog Devices provides a compact and efficient power solution for DC/DC conversion. With its integrated architecture, the module reduces design complexity and minimizes the need for external components. It offers excellent thermal performance while maintaining efficiency up to 92%, even under high-load conditions. Moreover, the device includes adjustable parameters such as soft-start and switching frequency, allowing easy customization. Its internal protection features improve system reliability, while the compact 15mm × 15mm × 2.8mm LGA package supports dense layouts. Because of its fast transient response and thermal resilience, the LTM4602EV#PBF is ideal for demanding telecom, computing, and industrial applications.
