M38510/05503BEA Specifications
Manufacturer: National Semiconductor
Part Number: M38510/05503BEA
NSN: 5962-8765201EA
Product Type: Quad Voltage Comparator
Number of Comparators: 4
Comparator Type: Differential Voltage Comparator
Output Type: Open Collector Output
Logic Compatibility: TTL Compatible Output
Supply Voltage Range: 2 V to 36 V
Package Type: Ceramic DIP-14
Mounting Type: Through Hole
Military Specification: MIL-PRF-38510
Operating Temperature Range: -55°C to +125°C
Applications Class: Military and Aerospace Electronics
Packaging: Factory
Key Features
The M38510/05503BEA is a military grade quad voltage comparator designed for high reliability electronic systems. It integrates four independent comparator circuits within a single device. Additionally, the component is manufactured and screened according to MIL-PRF-38510 standards which ensures dependable performance in aerospace and defense electronics. Because voltage comparators detect threshold crossings in analog signals, engineers frequently use them in monitoring and control circuits. As a result, the M38510/05503BEA supports reliable signal comparison in demanding electronic environments.
Applications
Military avionics electronics
Radar and surveillance systems
Aerospace instrumentation hardware
Defense communication electronics
Power supply monitoring circuits
Signal threshold detection systems
Industrial control electronics
Automated test equipment
Product Overview
The M38510/05503BEA from National Semiconductor provides dependable comparator functionality for high reliability electronic systems. First, the device integrates four comparator channels which allows multiple signal comparisons within a single integrated circuit.
Additionally, the device supports a wide supply voltage range which allows flexible operation across many electronic designs. Because threshold detection circuits are essential in monitoring and control electronics, voltage comparators remain widely used in aerospace and defense systems.
Moreover, the ceramic DIP-14 package supports reliable operation across extreme temperature environments and rugged electronic assemblies. Engineers frequently use devices like the M38510 family in avionics electronics, radar systems, and defense instrumentation equipment.
Therefore, the M38510/05503BEA remains a reliable comparator solution for aerospace electronics, defense systems, and other high reliability electronic applications.
Contact Us
Cyndtek supplies new, factory-packaged National Semiconductor semiconductors and electronic components for aerospace, defense, and industrial procurement programs. Our inventory supports engineers, buyers, and procurement professionals sourcing reliable electronic components. For ordering details and current inventory availability, visit https://cyndtek.com/shop/.
For additional available stock, browse our full inventory.
