MAX4624EUT+T

MAX4624EUT+T Specifications

Manufacturer: Analog Devices
Part Number: MAX4624EUT+T
Product Type: Low-Voltage SPDT Analog Switch
Configuration: 1 SPDT
Number of Channels: 1
On-Resistance (Max): 1 Ω at 5V supply
Supply Voltage Range: 1.8 V to 5.5 V
Switching Time (Max): 50 ns (tON), 50 ns (tOFF)
Overcurrent Protection: Yes
Logic Compatibility: TTL-compatible at 5V supply
Package / Case: SOT-23-6
Operating Temperature Range: -40°C to +85°C
RoHS Status: RoHS Compliant

Key Features

The MAX4624EUT+T from Analog Devices is a low-on-resistance, low-voltage single-pole/double-throw (SPDT) analog switch designed for operation with a single supply voltage ranging from 1.8 V to 5.5 V. It offers a maximum on-resistance of 1 Ω when powered from a 5V supply, ensuring minimal signal distortion. The device features fast switching speeds with a maximum turn-on time (tON) of 50 ns and a turn-off time (tOFF) of 50 ns, making it suitable for high-speed applications. Additionally, the MAX4624EUT+T includes overcurrent protection to prevent damage from short circuits and excessive loads. Its digital logic inputs are TTL-compatible when using a 5V supply, facilitating easy interfacing with standard logic circuits. The switch is housed in a compact SOT-23-6 package, making it ideal for space-constrained designs.

Applications

Power routing in battery-operated equipment requiring efficient and reliable switching.
Audio and video signal routing in consumer electronics where low distortion is critical.
Low-voltage data-acquisition systems needing precise signal selection.
Communication circuits requiring fast and reliable signal switching.
PCMCIA cards and modems where compact and efficient switching solutions are essential.

Product Overview

Analog Devices’ MAX4624EUT+T is engineered to provide efficient and reliable signal switching for a variety of low-voltage applications. Its low on-resistance ensures minimal signal loss, while the fast switching times support high-speed operations. The inclusion of overcurrent protection enhances the device’s robustness, safeguarding it against potential damage from short circuits. The TTL-compatible logic inputs at a 5V supply simplify integration with standard digital circuits. Packaged in a space-saving SOT-23-6 form factor, the MAX4624EUT+T is well-suited for applications where board space is at a premium. Its wide supply voltage range and operating temperature make it versatile for use in diverse environments.
