MC9S08AW32CPUE

MC9S08AW32CPUE Specifications

Manufacturer: NXP Semiconductors
Part Number: MC9S08AW32CPUE
Product Type: 8-bit Microcontroller
Core Processor: S08
Core Size: 8-bit
Speed: 40 MHz
Connectivity: I2C, SCI, SPI
Peripherals: LVD, POR, PWM, WDT
Number of I/O: 54
Program Memory Size: 32 KB (32K x 8)
Program Memory Type: FLASH
RAM Size: 2 KB (2K x 8)
Data Converters: A/D 16x10b
Oscillator Type: Internal
Operating Temperature Range: -40°C to +85°C
Mounting Type: Surface Mount
Package / Case: 64-LQFP (10×10 mm)
RoHS Status: RoHS Compliant

Key Features

The MC9S08AW32CPUE from NXP Semiconductors is an 8-bit microcontroller featuring the S08 core operating at speeds up to 40 MHz. It offers 32 KB of FLASH program memory and 2 KB of RAM, providing ample space for code and data storage. The device includes multiple communication interfaces such as I2C, SCI, and SPI, facilitating versatile connectivity options. Integrated peripherals like Low Voltage Detect (LVD), Power-On Reset (POR), Pulse Width Modulation (PWM), and Watchdog Timer (WDT) enhance system reliability and functionality. With 54 general-purpose I/O pins, it supports extensive interfacing capabilities. The microcontroller also features a 16-channel 10-bit ADC for precise analog signal measurement. Its internal oscillator simplifies clock generation, reducing the need for external components. Designed to operate within a temperature range of -40°C to +85°C, it is suitable for various environmental conditions. The device is housed in a 64-pin LQFP package, making it compatible with standard surface-mount manufacturing processes.

Applications

Industrial control systems requiring reliable 8-bit processing
Consumer electronics needing efficient peripheral integration
Automotive applications demanding robust microcontroller solutions
Home automation devices with multiple I/O requirements
Embedded systems utilizing analog-to-digital conversion

Product Overview

NXP Semiconductors’ MC9S08AW32CPUE microcontroller combines high-performance 8-bit processing with a rich set of peripherals and communication interfaces, making it ideal for a wide range of embedded applications. Its 32 KB FLASH memory and 2 KB RAM accommodate substantial code and data storage needs. The inclusion of multiple communication protocols and 54 I/O pins allows for flexible system design and connectivity. Integrated features like the 16-channel 10-bit ADC and internal oscillator contribute to system efficiency and reduce external component requirements. Operating over a broad temperature range and housed in a standard 64-LQFP package, this microcontroller offers a reliable solution for developers seeking a balance between performance and integration.
