MP2162AGQH-Z Specifications
Manufacturer: Monolithic Power Systems
Part Number: MP2162AGQH-Z
Device Type: Synchronous buck regulator
Regulator Topology: Step-down DC to DC converter
Input Voltage Range: 2.5 V to 6.0 V
Output Voltage Range: Adjustable with 0.6 V reference
Maximum Output Current: 2 A
Switching Frequency: 1.5 MHz typical
Control Method: PWM current-mode control
Quiescent Current: Ultra-low, light-load optimized
Efficiency Features: Synchronous rectification with pulse-skip mode
Protection Features: Cycle-by-cycle current limit, short-circuit protection, thermal shutdown
Enable Control: Logic enable with low shutdown current
Operating Temperature Range: -40 °C to +125 °C
Package Type: QFN-8 surface mount
Packaging Type: Tape and reel
Key Features
This synchronous buck regulator is designed for efficient point-of-load power conversion. It delivers up to 2 A output while maintaining high efficiency. Additionally, the high switching frequency allows the use of small external components. The ultra-low quiescent current improves performance during light-load operation. As a result, it supports longer battery life. Moreover, integrated protection features enhance system reliability. Therefore, it is well suited for compact and power-sensitive designs.
Applications
Microcontroller and processor core power rails
FPGA and DSP auxiliary voltage regulation
Battery-powered portable electronics
IoT devices and wireless modules
Embedded computing platforms
Consumer electronics power management
Industrial control low-voltage rails
USB-powered accessories
Wearable and handheld devices
Product Overview
The MP2162AGQH-Z from Monolithic Power Systems provides a compact solution for step-down voltage regulation in modern electronics. First, it converts low-voltage inputs into stable, adjustable outputs for sensitive loads. Additionally, its synchronous architecture improves efficiency across a wide load range. As designs continue to shrink, the 1.5 MHz switching frequency helps reduce external component size. Furthermore, the low quiescent current supports standby and always-on rails. Consequently, it performs well in battery-powered and portable systems. While compact, the device includes robust protection features to safeguard system operation. Therefore, it supports reliable performance in both consumer and industrial applications. Overall, this regulator balances efficiency, size, and functionality for point-of-load designs.
Contact Us
For pricing, availability, or technical questions regarding the MP2162AGQH-Z regulator, our team is ready to assist. Cyndtek supplies factory-new electronic components to support production and design requirements. Contact our sales team to discuss quantities and lead times. Email Sales@Cyndtek.com for prompt assistance.
For additional available stock, browse our full inventory.
