NB3M8302CDR2G Specifications
Manufacturer: onsemi
Part Number: NB3M8302CDR2G
Device Type: Clock buffer and level translator
Function: Differential to single-ended clock conversion
Input Signal Types: LVPECL, LVDS, and CML compatible
Output Signal Type: Single-ended CMOS or TTL
Supply Voltage: 3.3 V
Frequency Range: DC to 600 MHz
Propagation Delay: 1.5 ns typical
Output Drive Current: Up to 12 mA
Enable Control: Logic-controlled output enable
Jitter Performance: Low additive jitter design
Package Type: TSSOP-16
Mounting Style: Surface mount
Operating Temperature Range: -40 °C to +85 °C
Packaging Type: Tape and reel
Key Features
This device provides reliable clock buffering for mixed-signal systems. It supports multiple differential input standards. As a result, design flexibility improves. The low propagation delay helps preserve timing margins. Additionally, the low jitter design maintains signal integrity. The enable pin allows output control when needed. Therefore, power management becomes easier. The TSSOP package supports compact layouts. It also integrates well into automated assembly.
Applications
FPGA and ASIC clock distribution
PCI and PCI Express reference clocks
SerDes timing circuits
Telecommunications infrastructure
Networking and switching equipment
Embedded computing platforms
Industrial timing control systems
Mixed-signal clock translation
Product Overview
The NB3M8302CDR2G from onsemi is designed for dependable clock translation and distribution. First, it accepts differential inputs such as LVPECL, LVDS, and CML. Then, it converts those signals to single-ended CMOS or TTL outputs. Because of this, it simplifies clock domain interfacing.
Additionally, the device operates up to 600 MHz. This supports both low-speed and high-speed designs. The low propagation delay helps maintain tight timing budgets. As a result, system synchronization improves. The enable control pin allows clocks to be gated when required. Therefore, designers can reduce unnecessary switching.
The surface-mount TSSOP package saves board space. It also supports reliable soldering during reflow. Overall, this clock buffer balances flexibility, performance, and integration. It fits well in modern digital and mixed-signal systems.
