NCP45560IMNTWG-H

NCP45560IMNTWG-H Specifications

Manufacturer: onsemi
Part Type: Load Switch with Integrated NMOS
On Resistance (RDS ON): 10 mΩ (typical)
Input Voltage Range: 0.8 V to 13.5 V
Continuous Current: 6 A
Control Interface: Active High Enable
Output Discharge: Yes
Reverse Current Blocking: Yes
Soft-Start: Integrated
Package Type: DFN-8 (3 mm × 3 mm)
Operating Temperature Range: -40°C to +125°C
ESD Protection: 2 kV (Human Body Model)
UVLO Protection: Yes
Rise Time: 300 µs (typical)
Mounting Type: Surface Mount
RoHS Compliant: Yes

Key Features

The NCP45560IMNTWG-H is a high-side load switch optimized for power distribution in space-constrained electronic systems. It features a low 10 mΩ on-resistance NMOS for efficient power delivery and minimal heat dissipation. With support for a wide input range from 0.8 V to 13.5 V, it provides versatility across different voltage rails. Integrated reverse current blocking, soft-start, and output discharge ensure safe and stable operation. Its compact DFN-8 package and wide operating temperature range make it a reliable choice for high-performance applications.

Applications

Solid-state drive power control
CPU and GPU power switching
Portable medical instruments
Telecom and networking equipment
Industrial automation modules
Tablet and notebook power rails
Embedded computing platforms
Battery-operated devices
PCIe slot power distribution
Fan and peripheral control systems

Product Overview

Engineered for advanced load management, the NCP45560IMNTWG-H enables precise control over high-current paths in both consumer and industrial designs. It integrates a fast, low-resistance NMOS switch with reverse current protection, making it suitable for regulated or battery-powered rails. Its built-in soft-start and controlled rise time minimize inrush current and reduce stress on power components. The active-high enable input simplifies integration into microcontroller-based systems. Thanks to its compact footprint and robust protection features, it delivers reliable performance under demanding thermal and electrical conditions.
