NTF6P02T3G

NTF6P02T3G Specifications

Manufacturer: onsemi
Part Number: NTF6P02T3G
Product Type: P-Channel Power MOSFET
Drain-to-Source Voltage: -20 V
Continuous Drain Current: -10 A
Maximum On-Resistance: 50 mΩ at -4.5 V gate drive
Gate Charge: 20 nC at -4.5 V gate drive
Input Capacitance: 1200 pF at -16 V drain-to-source voltage
Power Dissipation: 8.3 W at 25°C ambient temperature
Package / Case: SOT-223 (TO-261)
Mounting Type: Surface Mount
Operating Temperature Range: -55°C to +150°C
RoHS Status: RoHS Compliant

Key Features

The NTF6P02T3G is a high-efficiency P-Channel MOSFET designed for power switching applications. It provides a low on-resistance of 50 mΩ, reducing conduction losses and improving system efficiency. Its gate charge of 20 nC allows for fast switching, making it ideal for high-speed applications. Additionally, its 1200 pF input capacitance enhances responsiveness in dynamic power environments. The device’s compact SOT-223 package supports surface mount designs, optimizing board space for various applications.

Applications

Power management systems
Load switching
DC-DC converters
Battery protection circuits
Motor control

Product Overview

The NTF6P02T3G from onsemi delivers reliable performance in applications requiring efficient switching with minimal power loss. Its low on-resistance enhances thermal efficiency, while its fast switching capability enables high-frequency operation. Designed for compact circuit layouts, it features a small SOT-223 package, making it suitable for space-constrained applications. The MOSFET operates over a wide temperature range, ensuring stability under varying conditions. Compliance with RoHS standards further ensures it meets environmental and safety requirements.
