NTMFS4C08NT1G

NTMFS4C08NT1G Specifications

Manufacturer: onsemi
Part Number: NTMFS4C08NT1G
Product Type: N-Channel Power MOSFET
Drain-to-Source Voltage: 30 V
Continuous Drain Current: 52 A at TC = 25°C
Pulsed Drain Current: 144 A
RDS(on) Max at VGS = 10 V: 5.8 mΩ
Gate Threshold Voltage: 1.3 V to 2.1 V
Total Gate Charge: 8.4 nC
Input Capacitance: 1113 pF
Operating Temperature Range: -55°C to +150°C
Package / Case: SO-8FL (5 x 6 mm)
Mounting Type: Surface Mount
Polarity: N-Channel
RoHS Status: RoHS Compliant

Key Features

The NTMFS4C08NT1G by onsemi is a compact and efficient N-channel MOSFET optimized for low-voltage switching applications. With a drain-to-source voltage rating of 30 V and a maximum continuous drain current of 52 A, it handles high-current loads while maintaining minimal conduction losses. Its low RDS(on) of 5.8 mΩ improves power efficiency in high-frequency circuits. Furthermore, its fast switching enabled by a low gate charge of 8.4 nC allows for performance in compact, high-speed systems. The thermally enhanced SO-8FL package offers improved heat dissipation, ideal for compact PCB designs where efficiency and reliability matter most.

Applications

High-efficiency synchronous rectifiers in power supplies
DC-DC converters for servers and telecom
Motor drivers in battery-operated tools
Load switching for industrial control boards
Power management in consumer electronics

Product Overview

onsemi’s NTMFS4C08NT1G delivers robust power switching performance in space-constrained applications. It combines high current capability with a low RDS(on) to reduce power losses, especially in DC-DC conversion stages and motor control systems. With excellent thermal behavior and compact packaging, it supports designers in achieving both energy efficiency and reliability. Its gate characteristics enable fast, clean transitions, helping to minimize EMI and heat. Designed for surface mounting, the device is ideal for cost-sensitive designs that require high performance under a range of environmental conditions.
