PCM1742KE/2K Specifications
Manufacturer: Texas Instruments
Part Number: PCM1742KE/2K
Product Type: 24-Bit, 192-kHz Sampling Enhanced Multilevel Delta-Sigma Audio Digital-to-Analog Converter (DAC)
Resolution: 24 bits
Sampling Frequency: 5 kHz to 200 kHz
Dynamic Range: 106 dB typical
Signal-to-Noise Ratio (SNR): 106 dB typical
Total Harmonic Distortion + Noise (THD+N): 0.002% typical
System Clock Multiples: 128 fS, 192 fS, 256 fS, 384 fS, 512 fS, 768 fS with autodetect
Audio Data Formats: Standard, I²S, and left-justified
User-Programmable Mode Controls: Digital attenuation (0 dB to -63 dB, 0.5 dB/step), digital de-emphasis, digital filter rolloff (sharp or slow), soft mute, zero flags for each output
Power Supply Requirements: Analog 5 V, Digital 3.3 V (5 V tolerant digital inputs)
Output Voltage (Full-Scale): 3.1 V peak-to-peak typical
Package / Case: 16-Lead SSOP
Mounting Type: Surface Mount
Operating Temperature Range: -25°C to +85°C
RoHS Status: RoHS Compliant
Key Features
The PCM1742KE/2K is a high-performance stereo DAC designed for premium audio applications. It uses an enhanced multilevel delta-sigma architecture to achieve outstanding dynamic performance and reduce clock jitter. This ensures accurate digital-to-analog conversion with minimal distortion. The device supports a wide range of sampling frequencies, from 5 kHz to 200 kHz, making it adaptable for many audio systems.
It accepts 16-, 18-, 20-, and 24-bit audio data in standard, I²S, and left-justified formats. Additionally, its user-programmable functions include digital attenuation, de-emphasis, filter rolloff selection, soft mute, and zero flag detection. These features allow for greater flexibility in system design. The DAC operates on a dual-supply voltage of 5 V for analog and 3.3 V for digital, with 5 V tolerant digital inputs. Its compact 16-lead SSOP package makes it easy to integrate into space-limited designs.
Applications
AV receivers
Movie players
DVD add-on cards for high-end PCs
DVD audio players
HDTV receivers
Car audio systems
Other applications requiring 24-bit audio
Product Overview
The PCM1742KE/2K from Texas Instruments provides exceptional audio performance in applications that require high-resolution digital-to-analog conversion. Its delta-sigma architecture ensures low noise and distortion, delivering a dynamic range of 106 dB and a THD+N of 0.002% typical. This makes it ideal for systems that demand precise and clear sound reproduction.
Because it supports multiple audio formats and sampling rates, this DAC offers flexibility for different applications. The programmable features allow for customization, ensuring compatibility with various system requirements. Its dual-supply operation enhances versatility, while the 5 V tolerant digital inputs simplify integration with existing hardware. Additionally, the compact SSOP package supports efficient surface-mount assembly. Compliance with RoHS standards confirms its suitability for environmentally responsible designs.
