PIC18F45K50-I/MV

PIC18F45K50-I/MV

$2.50

IC MCU 8BIT 32KB FLASH 40UQFN
  • Manufacturer: Microchip
  • Part Number: PIC18F45K50-I/MV
  • Packaging: Tape and Reel
  • Quantity: Each
  • Datecode: 22+

Availability: 114 in stock

SKU TSX060A Category Brand:

PIC18F45K50-I/MV Specifications

Manufacturer: Microchip Technology
Part Number: PIC18F45K50-I/MV
Product Type: 8-bit Microcontroller
Core Processor: PIC
Core Size: 8-Bit
Maximum Clock Frequency: 48 MHz
Program Memory Size: 32 KB Flash
RAM Size: 2 KB
EEPROM Size: 256 Bytes
I/O Pins: 33
ADC Resolution: 10-bit
ADC Channels: 25
Peripherals: POR, PWM, WDT, Brown-out Detect
Connectivity: I2C, SPI, UART/USART, USB
Oscillator Type: Internal
Supply Voltage Range: 2.3 V to 5.5 V
Package / Case: 40-UQFN (5×5 mm)
Mounting Type: Surface Mount
Operating Temperature Range: -40°C to +85°C
RoHS Status: RoHS Compliant

Key Features

The PIC18F45K50-I/MV is an 8-bit microcontroller designed to deliver high performance in embedded systems. It operates at speeds up to 48 MHz and includes 32 KB of Flash memory. Additionally, it integrates 2 KB of RAM and 256 bytes of EEPROM, offering space for runtime variables and non-volatile data.

Because it includes 33 I/O pins and a 10-bit ADC with 25 channels, the device supports a wide range of input configurations. Built-in peripherals such as Brown-out Reset, Power-On Reset, Watchdog Timer, and PWM enhance its reliability. Its USB interface and internal oscillator reduce the need for external components and simplify board design.

Applications

Consumer electronics with USB-enabled functions
Industrial controllers requiring flexible I/O
Embedded systems with analog sensor inputs
Medical devices needing secure program storage
Networking peripherals with low power demands

Product Overview

The PIC18F45K50-I/MV from Microchip offers flexibility, speed, and reliability in a compact 40-pin UQFN package. Its robust feature set makes it a strong choice for systems that need real-time control and analog integration. Designers can rely on its internal oscillator and broad supply range, which help simplify power design.

Its fast core and extensive interface support enable easy integration into both simple and complex embedded designs. Furthermore, its operating temperature range and surface-mount package suit commercial and industrial environments. Because of its USB connectivity and low power operation, this microcontroller supports modern applications where size and efficiency matter most.
